【HarmonyOS】鸿蒙实现刻度尺

import { RulerComponent } from '../../component/ruler/RulerComponent';

@Preview@Componentexport struct RulerComponent {  @Prop scaleWidth: number = 12 // 刻度间隔  @Prop totalScale: number = 33 //总刻度数  @Prop startScale: number = 1 //起始值  @Prop currentValue: number = 1.0 //当前值  @State totalArray: number[] = []  //总刻度  private scroller: Scroller = new Scroller();  scrollStopEvent: (scaleValue: number) => void = () => {  };
  aboutToAppear(): void {    // 根据总刻度，创建一个刻度值组成的数组，总刻度*10，是因为需要精确到小数据后一位，    for (let i = 1; i <= this.totalScale * 10; i++) {      if ((i / 10) >= this.startScale) {        this.totalArray.push(i);      }    }  }
  onDidBuild() {    //   计算滚动距离    let defaultScroll = (this.currentValue - this.startScale) * 10 * this.scaleWidth    this.scroller.scrollTo({ xOffset: defaultScroll, yOffset: 0 }) //吸附效果  }
  build() {    RelativeContainer() {      this.contentBuilder()    }    .height('100')    .width('100%');  }
  // 主题内容  @Builder  contentBuilder() {    Column() {      // 数值显示      Text(`${this.currentValue}    mmol/L`)        .fontSize(22)        .margin({ bottom: 18 })        .fontColor("#4ad5c6")      //   刻度尺主体      Stack() {        Scroll(this.scroller) {          Flex({ direction: FlexDirection.Row, alignItems: ItemAlign.Start }) {            ForEach(this.totalArray, (index: number) => {              this.CaleMarkBuilder(index % 10 === 0, (index / 10).toString())            })          }          .padding({            left: "50.5%",            right: "46%"          })        }        .scrollable(ScrollDirection.Horizontal)        .scrollBar(BarState.Off)        .onScrollStop(() => {          this.getScaleValue()        })
        //   中心指示器        this.Indicator()      }      .width("100%")      .border({        color: "#d4d5d7",        width: { top: 2 }      })      .clip(true)    }    .width("100%")    .padding({      left: 12,      right: 12    })  }
  //  刻度线和数据  @Builder  CaleMarkBuilder(isBold: boolean, boldText: string) {    RelativeContainer() {      Rect()        .width(2)        .height(isBold ? 30 : 20)        .fill('#d4d5d7')        .alignRules({          top: { anchor: "__container__", align: VerticalAlign.Top },          left: { anchor: "__container__", align: HorizontalAlign.Center }        })
      if (isBold) {        Text(boldText)          .fontSize(10)          .fontColor("#d4d5d7")          .width("100%")          .textAlign(TextAlign.Center)          .alignRules({            bottom: { anchor: "__container__", align: VerticalAlign.Bottom },          })      }    }    .width(this.scaleWidth)    .height(48)  }
  //中心指示器  @Builder  Indicator() {    Column() {      Text()        .width(0)        .height(0)        .border({          width: 10,          color: {            top: "#4ad5c6",            left: Color.Transparent,            right: Color.Transparent,            bottom: Color.Transparent          }        })      Rect()        .width(2)        .height(25)        .fill('#4ad5c6')        .position({ x: 9, y: 8 })    }    .position({ x: '50%', y: 0 })  }
  private getScaleValue() {    let x = this.scroller.currentOffset().xOffset //偏移距离    let endX: number = 0    //  四舍五入取整    const quotient = Math.floor(x / this.scaleWidth) //121=12.1    // 计算当前数字除以 10 的余数    const remainder = x % 10    // 如果余数小于 5，最近的 10 的倍数是商乘以 10    if (remainder < 5) {      endX = quotient * this.scaleWidth    }    // 如果余数大于等于 5，最近的 10 的倍数是（商 + 1）乘以 10    else {      endX = (quotient + 1) * this.scaleWidth    }    this.scroller.scrollTo({ xOffset: endX, yOffset: 0 }) //吸附效果    this.currentValue = (this.startScale + (endX / this.scaleWidth / 10))    this.scrollStopEvent(this.currentValue)  }}
