升级遇到坑？一文带你搞定 DolphinScheduler 2.0 到 3.0 升级

备份原始DS库： mysqldump -h ip -P 3306 -u 用户 -p 密码 数据库名  > /opt/new_dolphinscheduler.sql
恢复到新库：　　mysql -u 用户 –p 密码 数据库名 < 备份文件.sql

####此脚本是官网脚本改的，添加了字段/* * Licensed to the Apache Software Foundation (ASF) under one or more * contributor license agreements.  See the NOTICE file distributed with * this work for additional information regarding copyright ownership. * The ASF licenses this file to You under the Apache License, Version 2.0 * (the "License"); you may not use this file except in compliance with * the License.  You may obtain a copy of the License at * *    http://www.apache.org/licenses/LICENSE-2.0 * * Unless required by applicable law or agreed to in writing, software * distributed under the License is distributed on an "AS IS" BASIS, * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. * See the License for the specific language governing permissions and * limitations under the License.*/
SET sql_mode=(SELECT REPLACE(@@sql_mode,'ONLY_FULL_GROUP_BY',''));
-- uc_dolphin_T_t_ds_alert_R_signdrop PROCEDURE if EXISTS uc_dolphin_T_t_ds_alert_R_sign;delimiter d//CREATE PROCEDURE uc_dolphin_T_t_ds_alert_R_sign()BEGIN        IF NOT EXISTS (SELECT 1 FROM information_schema.COLUMNS            WHERE TABLE_NAME='t_ds_alert'            AND TABLE_SCHEMA=(SELECT DATABASE())            AND COLUMN_NAME='sign')    THENALTER TABLE `t_ds_alert` ADD COLUMN `sign` char(40) NOT NULL DEFAULT '' COMMENT 'sign=sha1(content)' after `id`;ALTER TABLE `t_ds_alert` ADD INDEX `idx_sign` (`sign`) USING BTREE;END IF;END;
d//
delimiter ;CALL uc_dolphin_T_t_ds_alert_R_sign;DROP PROCEDURE uc_dolphin_T_t_ds_alert_R_sign;
-- add unique key to t_ds_relation_project_userdrop PROCEDURE if EXISTS add_t_ds_relation_project_user_uk_uniq_uid_pid;delimiter d//CREATE PROCEDURE add_t_ds_relation_project_user_uk_uniq_uid_pid()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.STATISTICS        WHERE TABLE_NAME='t_ds_relation_project_user'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND INDEX_NAME='uniq_uid_pid')    THENALTER TABLE t_ds_relation_project_user ADD UNIQUE KEY uniq_uid_pid(user_id, project_id);END IF;END;
d//
delimiter ;# CALL add_t_ds_relation_project_user_uk_uniq_uid_pid;DROP PROCEDURE add_t_ds_relation_project_user_uk_uniq_uid_pid;
-- drop t_ds_relation_project_user key user_id_indexdrop PROCEDURE if EXISTS drop_t_ds_relation_project_user_key_user_id_index;delimiter d//CREATE PROCEDURE drop_t_ds_relation_project_user_key_user_id_index()BEGIN    IF EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.STATISTICS        WHERE TABLE_NAME='t_ds_relation_project_user'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND INDEX_NAME='user_id_index')    THENALTER TABLE `t_ds_relation_project_user` DROP KEY `user_id_index`;END IF;END;d//delimiter ;CALL drop_t_ds_relation_project_user_key_user_id_index;DROP PROCEDURE drop_t_ds_relation_project_user_key_user_id_index;
-- add unique key to t_ds_projectdrop PROCEDURE if EXISTS add_t_ds_project_uk_unique_name;delimiter d//CREATE PROCEDURE add_t_ds_project_uk_unique_name()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.STATISTICS        WHERE TABLE_NAME='t_ds_project'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND INDEX_NAME='unique_name')    THENALTER TABLE t_ds_project ADD UNIQUE KEY unique_name(name);END IF;END;d//delimiter ;CALL add_t_ds_project_uk_unique_name;DROP PROCEDURE add_t_ds_project_uk_unique_name;
drop PROCEDURE if EXISTS add_t_ds_project_uk_unique_code;delimiter d//CREATE PROCEDURE add_t_ds_project_uk_unique_code()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.STATISTICS        WHERE TABLE_NAME='t_ds_project'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND INDEX_NAME='unique_code')    THENALTER TABLE t_ds_project ADD UNIQUE KEY unique_code(code);END IF;END;d//delimiter ;CALL add_t_ds_project_uk_unique_code;DROP PROCEDURE add_t_ds_project_uk_unique_code;
-- add unique key to t_ds_queuedrop PROCEDURE if EXISTS add_t_ds_queue_uk_unique_queue_name;delimiter d//CREATE PROCEDURE add_t_ds_queue_uk_unique_queue_name()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.STATISTICS        WHERE TABLE_NAME='t_ds_queue'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND INDEX_NAME='unique_queue_name')    THENALTER TABLE t_ds_queue ADD UNIQUE KEY unique_queue_name(queue_name);END IF;END;d//delimiter ;CALL add_t_ds_queue_uk_unique_queue_name;DROP PROCEDURE add_t_ds_queue_uk_unique_queue_name;
-- add unique key to t_ds_udfsdrop PROCEDURE if EXISTS add_t_ds_udfs_uk_unique_func_name;delimiter d//CREATE PROCEDURE add_t_ds_udfs_uk_unique_func_name()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.STATISTICS        WHERE TABLE_NAME='t_ds_udfs'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND INDEX_NAME='unique_func_name')    THENALTER TABLE t_ds_udfs ADD UNIQUE KEY unique_func_name(func_name);END IF;END;d//delimiter ;CALL add_t_ds_udfs_uk_unique_func_name;DROP PROCEDURE add_t_ds_udfs_uk_unique_func_name;
-- add unique key to t_ds_tenantdrop PROCEDURE if EXISTS add_t_ds_tenant_uk_unique_tenant_code;delimiter d//CREATE PROCEDURE add_t_ds_tenant_uk_unique_tenant_code()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.STATISTICS        WHERE TABLE_NAME='t_ds_tenant'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND INDEX_NAME='unique_tenant_code')    THENALTER TABLE t_ds_tenant ADD UNIQUE KEY unique_tenant_code(tenant_code);END IF;END;d//delimiter ;CALL add_t_ds_tenant_uk_unique_tenant_code;DROP PROCEDURE add_t_ds_tenant_uk_unique_tenant_code;
-- ALTER TABLE `t_ds_task_instance` ADD INDEX `idx_code_version` (`task_code`, `task_definition_version`) USING BTREE;drop PROCEDURE if EXISTS add_t_ds_task_instance_uk_idx_code_version;delimiter d//CREATE PROCEDURE add_t_ds_task_instance_uk_idx_code_version()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.STATISTICS        WHERE TABLE_NAME='t_ds_task_instance'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND INDEX_NAME='idx_code_version')    THENALTER TABLE `t_ds_task_instance` ADD INDEX `idx_code_version` (`task_code`, `task_definition_version`) USING BTREE;END IF;END;d//delimiter ;CALL add_t_ds_task_instance_uk_idx_code_version;DROP PROCEDURE add_t_ds_task_instance_uk_idx_code_version;
-- ALTER TABLE `t_ds_task_instance` MODIFY COLUMN `task_params` longtext COMMENT 'job custom parameters' AFTER `app_link`;drop PROCEDURE if EXISTS modify_t_ds_task_instance_col_task_params;delimiter d//CREATE PROCEDURE modify_t_ds_task_instance_col_task_params()BEGIN    IF EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.COLUMNS        WHERE TABLE_NAME='t_ds_task_instance'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND COLUMN_NAME ='task_params')    THENALTER TABLE `t_ds_task_instance` MODIFY COLUMN `task_params` longtext COMMENT 'job custom parameters' AFTER `app_link`;END IF;END;d//delimiter ;CALL modify_t_ds_task_instance_col_task_params;DROP PROCEDURE modify_t_ds_task_instance_col_task_params;
-- ALTER TABLE `t_ds_task_instance` ADD COLUMN `task_group_id` int(11) DEFAULT NULL COMMENT 'task group id';drop PROCEDURE if EXISTS add_t_ds_task_instance_col_task_group_id;delimiter d//CREATE PROCEDURE add_t_ds_task_instance_col_task_group_id()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.COLUMNS        WHERE TABLE_NAME='t_ds_task_instance'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND COLUMN_NAME ='task_group_id')    THENALTER TABLE `t_ds_task_instance` ADD COLUMN `task_group_id` int(11) DEFAULT NULL COMMENT 'task group id' after `var_pool`;END IF;END;d//delimiter ;CALL add_t_ds_task_instance_col_task_group_id;DROP PROCEDURE add_t_ds_task_instance_col_task_group_id;
-- ALTER TABLE `t_ds_process_task_relation` ADD KEY `idx_code` (`project_code`, `process_definition_code`) USING BTREE;drop PROCEDURE if EXISTS add_t_ds_process_task_relation_key_idx_code;delimiter d//CREATE PROCEDURE add_t_ds_process_task_relation_key_idx_code()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.STATISTICS        WHERE TABLE_NAME='t_ds_process_task_relation'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND INDEX_NAME='idx_code')    THENALTER TABLE `t_ds_process_task_relation` ADD KEY `idx_code` (`project_code`, `process_definition_code`) USING BTREE;END IF;END;d//delimiter ;CALL add_t_ds_process_task_relation_key_idx_code;DROP PROCEDURE add_t_ds_process_task_relation_key_idx_code;
-- ALTER TABLE `t_ds_process_task_relation` ADD KEY `idx_pre_task_code_version` (`pre_task_code`,`pre_task_version`);drop PROCEDURE if EXISTS add_t_ds_process_task_relation_key_idx_pre_task_code_version;delimiter d//CREATE PROCEDURE add_t_ds_process_task_relation_key_idx_pre_task_code_version()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.STATISTICS        WHERE TABLE_NAME='t_ds_process_task_relation'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND INDEX_NAME='idx_pre_task_code_version')    THENALTER TABLE `t_ds_process_task_relation` ADD KEY `idx_pre_task_code_version` (`pre_task_code`,`pre_task_version`);END IF;END;d//delimiter ;CALL add_t_ds_process_task_relation_key_idx_pre_task_code_version;DROP PROCEDURE add_t_ds_process_task_relation_key_idx_pre_task_code_version;
-- ALTER TABLE `t_ds_process_task_relation` ADD KEY `idx_post_task_code_version` (`post_task_code`,`post_task_version`);drop PROCEDURE if EXISTS add_t_ds_process_task_relation_key_idx_post_task_code_version;delimiter d//CREATE PROCEDURE add_t_ds_process_task_relation_key_idx_post_task_code_version()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.STATISTICS        WHERE TABLE_NAME='t_ds_process_task_relation'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND INDEX_NAME='idx_post_task_code_version')    THENALTER TABLE `t_ds_process_task_relation` ADD KEY `idx_post_task_code_version` (`post_task_code`,`post_task_version`);END IF;END;d//delimiter ;CALL add_t_ds_process_task_relation_key_idx_post_task_code_version;DROP PROCEDURE add_t_ds_process_task_relation_key_idx_post_task_code_version;
-- ALTER TABLE `t_ds_process_task_relation_log` ADD KEY `idx_process_code_version` (`process_definition_code`,`process_definition_version`) USING BTREE;drop PROCEDURE if EXISTS add_t_ds_process_task_relation_key_idx_process_code_version;delimiter d//CREATE PROCEDURE add_t_ds_process_task_relation_key_idx_process_code_version()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.STATISTICS        WHERE TABLE_NAME='t_ds_process_task_relation_log'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND INDEX_NAME='idx_process_code_version')    THENALTER TABLE `t_ds_process_task_relation_log` ADD KEY `idx_process_code_version` (`process_definition_code`,`process_definition_version`) USING BTREE;END IF;END;d//delimiter ;CALL add_t_ds_process_task_relation_key_idx_process_code_version;DROP PROCEDURE add_t_ds_process_task_relation_key_idx_process_code_version;
-- ALTER TABLE `t_ds_task_definition_log` ADD INDEX `idx_project_code` (`project_code`) USING BTREE;drop PROCEDURE if EXISTS add_t_ds_task_definition_log_key_idx_process_code_version;delimiter d//CREATE PROCEDURE add_t_ds_task_definition_log_key_idx_process_code_version()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.STATISTICS        WHERE TABLE_NAME='t_ds_task_definition_log'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND INDEX_NAME='idx_project_code')    THENALTER TABLE `t_ds_task_definition_log` ADD INDEX `idx_project_code` (`project_code`) USING BTREE;END IF;END;d//delimiter ;CALL add_t_ds_task_definition_log_key_idx_process_code_version;DROP PROCEDURE add_t_ds_task_definition_log_key_idx_process_code_version;
-- ALTER TABLE `t_ds_task_definition_log` ADD INDEX `idx_code_version` (`code`,`version`) USING BTREE;drop PROCEDURE if EXISTS add_t_ds_task_definition_log_key_idx_code_version;delimiter d//CREATE PROCEDURE add_t_ds_task_definition_log_key_idx_code_version()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.STATISTICS        WHERE TABLE_NAME='t_ds_task_definition_log'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND INDEX_NAME='idx_code_version')    THENALTER TABLE `t_ds_task_definition_log` ADD INDEX `idx_code_version` (`code`,`version`) USING BTREE;END IF;END;d//delimiter ;CALL add_t_ds_task_definition_log_key_idx_code_version;DROP PROCEDURE add_t_ds_task_definition_log_key_idx_code_version;
-- alter table t_ds_task_definition_log add `task_group_id` int(11) DEFAULT NULL COMMENT 'task group id' AFTER `resource_ids`;drop PROCEDURE if EXISTS add_t_ds_task_definition_log_col_task_group_id;delimiter d//CREATE PROCEDURE add_t_ds_task_definition_log_col_task_group_id()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.COLUMNS        WHERE TABLE_NAME='t_ds_task_definition_log'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND COLUMN_NAME='task_group_id')    THENalter table t_ds_task_definition_log add `task_group_id` int(11) DEFAULT NULL COMMENT 'task group id' AFTER `resource_ids`;END IF;END;d//delimiter ;CALL add_t_ds_task_definition_log_col_task_group_id;DROP PROCEDURE add_t_ds_task_definition_log_col_task_group_id;
-- alter table t_ds_task_definition_log add `task_group_id` int(11) DEFAULT NULL COMMENT 'task group id' AFTER `resource_ids`;drop PROCEDURE if EXISTS add_t_ds_task_definition_col_task_group_id;delimiter d//CREATE PROCEDURE add_t_ds_task_definition_col_task_group_id()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.COLUMNS        WHERE TABLE_NAME='t_ds_task_definition'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND COLUMN_NAME='task_group_id')    THENalter table t_ds_task_definition add `task_group_id` int DEFAULT NULL COMMENT 'task group id';END IF;END;d//delimiter ;CALL add_t_ds_task_definition_col_task_group_id;DROP PROCEDURE add_t_ds_task_definition_col_task_group_id;
-- alter table t_ds_task_definition_log add `task_group_priority` int(11) DEFAULT NULL COMMENT 'task group id' AFTER `task_group_id`;drop PROCEDURE if EXISTS add_t_ds_task_definition_log_col_task_group_priority;delimiter d//CREATE PROCEDURE add_t_ds_task_definition_log_col_task_group_priority()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.COLUMNS        WHERE TABLE_NAME='t_ds_task_definition_log'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND COLUMN_NAME='task_group_priority')    THENalter table t_ds_task_definition_log add `task_group_priority` tinyint DEFAULT '0' COMMENT 'task group priority' AFTER `task_group_id`;END IF;END;d//delimiter ;CALL add_t_ds_task_definition_log_col_task_group_priority;DROP PROCEDURE add_t_ds_task_definition_log_col_task_group_priority;
-- alter table t_ds_task_definition add `task_group_priority` int(11) DEFAULT '0' COMMENT 'task group id' AFTER `task_group_id`;drop PROCEDURE if EXISTS add_t_ds_task_definition_col_task_group_priority;delimiter d//CREATE PROCEDURE add_t_ds_task_definition_col_task_group_priority()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.COLUMNS        WHERE TABLE_NAME='t_ds_task_definition'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND COLUMN_NAME='task_group_priority')    THENalter table t_ds_task_definition add `task_group_priority` tinyint DEFAULT '0' COMMENT 'task group priority' AFTER `task_group_id`;END IF;END;d//delimiter ;CALL add_t_ds_task_definition_col_task_group_priority;DROP PROCEDURE add_t_ds_task_definition_col_task_group_priority;
-- ALTER TABLE `t_ds_user` ADD COLUMN `time_zone` varchar(32) DEFAULT NULL COMMENT 'time zone';drop PROCEDURE if EXISTS add_t_ds_user_col_time_zone;delimiter d//CREATE PROCEDURE add_t_ds_user_col_time_zone()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.COLUMNS        WHERE TABLE_NAME='t_ds_user'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND COLUMN_NAME='time_zone')    THENALTER TABLE `t_ds_user` ADD COLUMN `time_zone` varchar(32) DEFAULT NULL COMMENT 'time zone';END IF;END;d//delimiter ;CALL add_t_ds_user_col_time_zone;DROP PROCEDURE add_t_ds_user_col_time_zone;
-- ALTER TABLE `t_ds_alert` ADD COLUMN `warning_type` tinyint(4) DEFAULT '2' COMMENT '1 process is successfully, 2 process/task is failed';drop PROCEDURE if EXISTS add_t_ds_alert_col_warning_type;delimiter d//CREATE PROCEDURE add_t_ds_alert_col_warning_type()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.COLUMNS        WHERE TABLE_NAME='t_ds_alert'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND COLUMN_NAME='warning_type')    THENALTER TABLE `t_ds_alert` ADD COLUMN `warning_type` tinyint(4) DEFAULT '2' COMMENT '1 process is successfully, 2 process/task is failed';END IF;END;d//delimiter ;CALL add_t_ds_alert_col_warning_type;DROP PROCEDURE add_t_ds_alert_col_warning_type;
-- ALTER TABLE `t_ds_alert` ADD INDEX `idx_status` (`alert_status`) USING BTREE;drop PROCEDURE if EXISTS add_t_ds_alert_idx_idx_status;delimiter d//CREATE PROCEDURE add_t_ds_alert_idx_idx_status()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.STATISTICS        WHERE TABLE_NAME='t_ds_alert'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND INDEX_NAME='idx_status')    THENALTER TABLE `t_ds_alert` ADD INDEX `idx_status` (`alert_status`) USING BTREE;END IF;END;d//delimiter ;CALL add_t_ds_alert_idx_idx_status;DROP PROCEDURE add_t_ds_alert_idx_idx_status;
-- ALTER TABLE `t_ds_alert` ADD COLUMN `project_code` bigint DEFAULT NULL COMMENT 'project_code';-- ALTER TABLE `t_ds_alert` ADD COLUMN `process_definition_code` bigint DEFAULT NULL COMMENT 'process_definition_code';-- ALTER TABLE `t_ds_alert` ADD COLUMN `process_instance_id` int DEFAULT NULL COMMENT 'process_instance_id';-- ALTER TABLE `t_ds_alert` ADD COLUMN `alert_type` int DEFAULT NULL COMMENT 'alert_type';drop PROCEDURE if EXISTS add_t_ds_alert_col_project_code;delimiter d//CREATE PROCEDURE add_t_ds_alert_col_project_code()BEGIN    IF NOT EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.COLUMNS        WHERE TABLE_NAME='t_ds_alert'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND COLUMN_NAME='project_code')    THENALTER TABLE `t_ds_alert` ADD COLUMN `project_code` bigint DEFAULT NULL COMMENT 'project_code';ALTER TABLE `t_ds_alert` ADD COLUMN `process_definition_code` bigint DEFAULT NULL COMMENT 'process_definition_code';ALTER TABLE `t_ds_alert` ADD COLUMN `process_instance_id` int DEFAULT NULL COMMENT 'process_instance_id';ALTER TABLE `t_ds_alert` ADD COLUMN `alert_type` int DEFAULT NULL COMMENT 'alert_type';END IF;END;d//delimiter ;# CALL add_t_ds_alert_col_project_code;DROP PROCEDURE add_t_ds_alert_col_project_code;
-- t_ds_task_instancedrop PROCEDURE if EXISTS alter_t_ds_task_instance_col_log_path;delimiter d//CREATE PROCEDURE alter_t_ds_task_instance_col_log_path()BEGIN    IF EXISTS (SELECT 1 FROM INFORMATION_SCHEMA.COLUMNS        WHERE TABLE_NAME='t_ds_task_instance'        AND TABLE_SCHEMA=(SELECT DATABASE())        AND COLUMN_NAME='log_path')    THENALTER TABLE `t_ds_task_instance` MODIFY COLUMN `log_path` longtext DEFAULT NULL COMMENT 'task log path';END IF;END;d//delimiter ;CALL alter_t_ds_task_instance_col_log_path;DROP PROCEDURE alter_t_ds_task_instance_col_log_path;
---- Table structure for table `t_ds_dq_comparison_type`--DROP TABLE IF EXISTS `t_ds_dq_comparison_type`;CREATE TABLE `t_ds_dq_comparison_type` (                                           `id` int(11) NOT NULL AUTO_INCREMENT,                                           `type` varchar(100) NOT NULL,                                           `execute_sql` text DEFAULT NULL,                                           `output_table` varchar(100) DEFAULT NULL,                                           `name` varchar(100) DEFAULT NULL,                                           `create_time` datetime DEFAULT NULL,                                           `update_time` datetime DEFAULT NULL,                                           `is_inner_source` tinyint(1) DEFAULT '0',                                           PRIMARY KEY (`id`))ENGINE=InnoDB DEFAULT CHARSET=utf8;
---- Table structure for table t_ds_dq_execute_result--DROP TABLE IF EXISTS `t_ds_dq_execute_result`;CREATE TABLE `t_ds_dq_execute_result` (                                          `id` int(11) NOT NULL AUTO_INCREMENT,                                          `process_definition_id` int(11) DEFAULT NULL,                                          `process_instance_id` int(11) DEFAULT NULL,                                          `task_instance_id` int(11) DEFAULT NULL,                                          `rule_type` int(11) DEFAULT NULL,                                          `rule_name` varchar(255) DEFAULT NULL,                                          `statistics_value` double DEFAULT NULL,                                          `comparison_value` double DEFAULT NULL,                                          `check_type` int(11) DEFAULT NULL,                                          `threshold` double DEFAULT NULL,                                          `operator` int(11) DEFAULT NULL,                                          `failure_strategy` int(11) DEFAULT NULL,                                          `state` int(11) DEFAULT NULL,                                          `user_id` int(11) DEFAULT NULL,                                          `comparison_type` int(11) DEFAULT NULL,                                          `error_output_path` text DEFAULT NULL,                                          `create_time` datetime DEFAULT NULL,                                          `update_time` datetime DEFAULT NULL,                                          PRIMARY KEY (`id`)) ENGINE=InnoDB DEFAULT CHARSET=utf8;
---- Table structure for table t_ds_dq_rule--DROP TABLE IF EXISTS `t_ds_dq_rule`;CREATE TABLE `t_ds_dq_rule` (                                `id` int(11) NOT NULL AUTO_INCREMENT,                                `name` varchar(100) DEFAULT NULL,                                `type` int(11) DEFAULT NULL,                                `user_id` int(11) DEFAULT NULL,                                `create_time` datetime DEFAULT NULL,                                `update_time` datetime DEFAULT NULL,                                PRIMARY KEY (`id`)) ENGINE=InnoDB DEFAULT CHARSET=utf8;
---- Table structure for table t_ds_dq_rule_execute_sql--DROP TABLE IF EXISTS `t_ds_dq_rule_execute_sql`;CREATE TABLE `t_ds_dq_rule_execute_sql` (                                            `id` int(11) NOT NULL AUTO_INCREMENT,                                            `index` int(11) DEFAULT NULL,                                            `sql` text DEFAULT NULL,                                            `table_alias` varchar(255) DEFAULT NULL,                                            `type` int(11) DEFAULT NULL,                                            `is_error_output_sql` tinyint(1) DEFAULT '0',                                            `create_time` datetime DEFAULT NULL,                                            `update_time` datetime DEFAULT NULL,                                            PRIMARY KEY (`id`)) ENGINE=InnoDB DEFAULT CHARSET=utf8;
---- Table structure for table t_ds_dq_rule_input_entry--DROP TABLE IF EXISTS `t_ds_dq_rule_input_entry`;CREATE TABLE `t_ds_dq_rule_input_entry` (                                            `id` int(11) NOT NULL AUTO_INCREMENT,                                            `field` varchar(255) DEFAULT NULL,                                            `type` varchar(255) DEFAULT NULL,                                            `title` varchar(255) DEFAULT NULL,                                            `value` varchar(255)  DEFAULT NULL,                                            `options` text DEFAULT NULL,                                            `placeholder` varchar(255) DEFAULT NULL,                                            `option_source_type` int(11) DEFAULT NULL,                                            `value_type` int(11) DEFAULT NULL,                                            `input_type` int(11) DEFAULT NULL,                                            `is_show` tinyint(1) DEFAULT '1',                                            `can_edit` tinyint(1) DEFAULT '1',                                            `is_emit` tinyint(1) DEFAULT '0',                                            `is_validate` tinyint(1) DEFAULT '1',                                            `create_time` datetime DEFAULT NULL,                                            `update_time` datetime DEFAULT NULL,                                            PRIMARY KEY (`id`)) ENGINE=InnoDB DEFAULT CHARSET=utf8;
---- Table structure for table t_ds_dq_task_statistics_value--DROP TABLE IF EXISTS `t_ds_dq_task_statistics_value`;CREATE TABLE `t_ds_dq_task_statistics_value` (                                                 `id` int(11) NOT NULL AUTO_INCREMENT,                                                 `process_definition_id` int(11) DEFAULT NULL,                                                 `task_instance_id` int(11) DEFAULT NULL,                                                 `rule_id` int(11) NOT NULL,                                                 `unique_code` varchar(255) NULL,                                                 `statistics_name` varchar(255) NULL,                                                 `statistics_value` double NULL,                                                 `data_time` datetime DEFAULT NULL,                                                 `create_time` datetime DEFAULT NULL,                                                 `update_time` datetime DEFAULT NULL,                                                 PRIMARY KEY (`id`)) ENGINE=InnoDB DEFAULT CHARSET=utf8;
---- Table structure for table t_ds_relation_rule_execute_sql--DROP TABLE IF EXISTS `t_ds_relation_rule_execute_sql`;CREATE TABLE `t_ds_relation_rule_execute_sql` (                                                  `id` int(11) NOT NULL AUTO_INCREMENT,                                                  `rule_id` int(11) DEFAULT NULL,                                                  `execute_sql_id` int(11) DEFAULT NULL,                                                  `create_time` datetime NULL,                                                  `update_time` datetime NULL,                                                  PRIMARY KEY (`id`)) ENGINE=InnoDB DEFAULT CHARSET=utf8;
---- Table structure for table t_ds_relation_rule_input_entry--DROP TABLE IF EXISTS `t_ds_relation_rule_input_entry`;CREATE TABLE `t_ds_relation_rule_input_entry` (                                                  `id` int(11) NOT NULL AUTO_INCREMENT,                                                  `rule_id` int(11) DEFAULT NULL,                                                  `rule_input_entry_id` int(11) DEFAULT NULL,                                                  `values_map` text DEFAULT NULL,                                                  `index` int(11) DEFAULT NULL,                                                  `create_time` datetime DEFAULT NULL,                                                  `update_time` datetime DEFAULT NULL,                                                  PRIMARY KEY (`id`)) ENGINE=InnoDB DEFAULT CHARSET=utf8;

-- ------------------------------ Table structure for t_ds_k8s-- ----------------------------DROP TABLE IF EXISTS `t_ds_k8s`;CREATE TABLE `t_ds_k8s` (  `id` int(11) NOT NULL AUTO_INCREMENT,  `k8s_name` varchar(100) DEFAULT NULL,  `k8s_config` text DEFAULT NULL,  `create_time` datetime DEFAULT NULL COMMENT 'create time',  `update_time` datetime DEFAULT NULL COMMENT 'update time',  PRIMARY KEY (`id`)) ENGINE= INNODB AUTO_INCREMENT= 1 DEFAULT CHARSET= utf8;
-- ------------------------------ Table structure for t_ds_k8s_namespace-- ----------------------------DROP TABLE IF EXISTS `t_ds_k8s_namespace`;CREATE TABLE `t_ds_k8s_namespace` (  `id` int(11) NOT NULL AUTO_INCREMENT,  `limits_memory` int(11) DEFAULT NULL,  `namespace` varchar(100) DEFAULT NULL,  `online_job_num` int(11) DEFAULT NULL,  `user_id` int(11) DEFAULT NULL,  `pod_replicas` int(11) DEFAULT NULL,  `pod_request_cpu` decimal(14,3) DEFAULT NULL,  `pod_request_memory` int(11) DEFAULT NULL,  `limits_cpu` decimal(14,3) DEFAULT NULL,  `k8s` varchar(100) DEFAULT NULL,  `create_time` datetime DEFAULT NULL COMMENT 'create time',  `update_time` datetime DEFAULT NULL COMMENT 'update time',  PRIMARY KEY (`id`),  UNIQUE KEY `k8s_namespace_unique` (`namespace`,`k8s`)) ENGINE= INNODB AUTO_INCREMENT= 1 DEFAULT CHARSET= utf8;
-- ------------------------------ Table structure for t_ds_relation_namespace_user-- ----------------------------DROP TABLE IF EXISTS `t_ds_relation_namespace_user`;CREATE TABLE `t_ds_relation_namespace_user` (  `id` int(11) NOT NULL AUTO_INCREMENT COMMENT 'key',  `user_id` int(11) NOT NULL COMMENT 'user id',  `namespace_id` int(11) DEFAULT NULL COMMENT 'namespace id',  `perm` int(11) DEFAULT '1' COMMENT 'limits of authority',  `create_time` datetime DEFAULT NULL COMMENT 'create time',  `update_time` datetime DEFAULT NULL COMMENT 'update time',  PRIMARY KEY (`id`),  UNIQUE KEY `namespace_user_unique` (`user_id`,`namespace_id`)) ENGINE=InnoDB AUTO_INCREMENT= 1 DEFAULT CHARSET= utf8;
-- ------------------------------ Table structure for t_ds_alert_send_status-- ----------------------------DROP TABLE IF EXISTS t_ds_alert_send_status;CREATE TABLE t_ds_alert_send_status (    `id`                            int(11) NOT NULL AUTO_INCREMENT,    `alert_id`                      int(11) NOT NULL,    `alert_plugin_instance_id`      int(11) NOT NULL,    `send_status`                   tinyint(4) DEFAULT '0',    `log`                           text,    `create_time`                   datetime DEFAULT NULL COMMENT 'create time',    PRIMARY KEY (`id`),    UNIQUE KEY `alert_send_status_unique` (`alert_id`,`alert_plugin_instance_id`)) ENGINE=InnoDB AUTO_INCREMENT=1 DEFAULT CHARSET=utf8;
-- ------------------------------ Table structure for t_ds_audit_log-- ----------------------------DROP TABLE IF EXISTS `t_ds_audit_log`;CREATE TABLE `t_ds_audit_log` (    `id` bigint(11) NOT NULL AUTO_INCREMENT COMMENT'key',    `user_id` int(11) NOT NULL COMMENT 'user id',    `resource_type` int(11) NOT NULL COMMENT 'resource type',    `operation` int(11) NOT NULL COMMENT 'operation',    `time` datetime DEFAULT CURRENT_TIMESTAMP COMMENT 'create time',    `resource_id` int(11) NULL DEFAULT NULL COMMENT 'resource id',    PRIMARY KEY (`id`)) ENGINE=InnoDB AUTO_INCREMENT= 1 DEFAULT CHARSET=utf8;
-- ------------------------------ Table structure for t_ds_task_group-- ----------------------------DROP TABLE IF EXISTS `t_ds_task_group`;CREATE TABLE `t_ds_task_group` (   `id`  int(11)  NOT NULL AUTO_INCREMENT COMMENT'key',   `name` varchar(100) DEFAULT NULL COMMENT 'task_group name',   `description` varchar(200) DEFAULT NULL,   `group_size` int (11) NOT NULL COMMENT'group size',   `use_size` int (11) DEFAULT '0' COMMENT 'used size',   `user_id` int(11) DEFAULT NULL COMMENT 'creator id',   `project_code` bigint(20) DEFAULT 0 COMMENT 'project code',   `status` tinyint(4) DEFAULT '1' COMMENT '0 not available, 1 available',   `create_time` timestamp NULL DEFAULT CURRENT_TIMESTAMP,   `update_time` timestamp NULL DEFAULT CURRENT_TIMESTAMP ON UPDATE CURRENT_TIMESTAMP,   PRIMARY KEY(`id`)) ENGINE= INNODB AUTO_INCREMENT= 1 DEFAULT CHARSET= utf8;
-- ------------------------------ Table structure for t_ds_task_group_queue-- ----------------------------DROP TABLE IF EXISTS `t_ds_task_group_queue`;CREATE TABLE `t_ds_task_group_queue` (   `id` int(11) NOT NULL AUTO_INCREMENT COMMENT'key',   `task_id` int(11) DEFAULT NULL COMMENT 'taskintanceid',   `task_name` varchar(100) DEFAULT NULL COMMENT 'TaskInstance name',   `group_id`  int(11) DEFAULT NULL COMMENT 'taskGroup id',   `process_id` int(11) DEFAULT NULL COMMENT 'processInstace id',   `priority` int(8) DEFAULT '0' COMMENT 'priority',   `status` tinyint(4) DEFAULT '-1' COMMENT '-1: waiting  1: running  2: finished',   `force_start` tinyint(4) DEFAULT '0' COMMENT 'is force start 0 NO ,1 YES',   `in_queue` tinyint(4) DEFAULT '0' COMMENT 'ready to get the queue by other task finish 0 NO ,1 YES',   `create_time` timestamp NULL DEFAULT CURRENT_TIMESTAMP,   `update_time` timestamp NULL DEFAULT CURRENT_TIMESTAMP ON UPDATE CURRENT_TIMESTAMP,   PRIMARY KEY( `id` ))ENGINE= INNODB AUTO_INCREMENT= 1 DEFAULT CHARSET= utf8;

ALTER TABLE t_ds_process_instance ADD`next_process_instance_id` int(11) DEFAULT '0' COMMENT 'serial queue next processInstanceId';ALTER TABLE t_ds_process_instance ADD `restart_time` datetime DEFAULT NULL COMMENT 'process instance restart time';ALTER TABLE t_ds_process_definition ADD   `execution_type` tinyint(4) DEFAULT '0' COMMENT 'execution_type 0:parallel,1:serial wait,2:serial discard,3:serial priority';ALTER TABLE t_ds_process_definition_log ADD   `execution_type` tinyint(4) DEFAULT '0' COMMENT 'execution_type 0:parallel,1:serial wait,2:serial discard,3:serial priority';

#项目表truncate table t_ds_project;
insert into t_ds_projectselect id,       name,       code,       description,       user_id,       flag,       create_time,       update_timefrom dolphin201.t_ds_project;
#任务过程定义####唯一dagtruncate table t_ds_process_definition;
insert into t_ds_process_definitionselect id,       code,       name,       version,       description,       project_code,       release_state,       user_id,       global_params,       flag,       locations,       warning_group_id,       timeout,       tenant_id,       execution_type,       create_time,       update_time from dolphin201.t_ds_process_definition;

#任务过程定义日志truncate table t_ds_process_definition_log;
insert into t_ds_process_definition_logselect t1.id,       t1.code,       t1.name,       t1.version,       t1.description,       t1.project_code,       t1.release_state,       t1.user_id,       t1.global_params,       t1.flag,       t1.locations,       t1.warning_group_id,       t1.timeout,       t1.tenant_id,       t1.execution_type,       t1.operator,       t1.operate_time,       t1.create_time,       t1.update_time
from dolphin201.t_ds_process_definition_log t1         inner join (select code, project_code, max(version) version                     from dolphin201.t_ds_process_definition_log                     group by project_code, code) t2                    on t1.code = t2.code and t1.project_code = t2.project_code and t1.version = t2.version                   ;
###进行任务相关性表truncate table t_ds_process_task_relation;
insert into t_ds_process_task_relationselect id,       name,       project_code,       process_definition_code,       process_definition_version,       pre_task_code,       pre_task_version,       post_task_code,       post_task_version,       condition_type,       condition_params,       create_time,       update_timefrom dolphin201.t_ds_process_task_relation;
###进行任务相关性表日志truncate table t_ds_process_task_relation_log;
insert into t_ds_process_task_relation_logselect t3.id,       t3.name,       t3.project_code,       t3.process_definition_code,       t3.process_definition_version,       t3.pre_task_code,       t3.pre_task_version,       t3.post_task_code,       t3.post_task_version,       t3.condition_type,       t3.condition_params,       t3.operator,       t3.operate_time,       t3.create_time,       t3.update_time # from t_ds_process_task_relation;from dolphin201.t_ds_process_task_relation_log t3         inner join (select project_code,                            process_definition_code,                            post_task_code,                            max(process_definition_version) process_definition_version,                            max(post_task_version) AS       post_task_version                     from dolphin201.t_ds_process_task_relation_log                     group by project_code, process_definition_code, post_task_code) t4                    on t3.project_code = t4.project_code                        and t3.process_definition_code = t4.process_definition_code                        and t3.post_task_code = t4.post_task_code                        and t3.process_definition_version = t4.process_definition_version                        and t3.post_task_version = t4.post_task_version;
###任务定义truncate table t_ds_task_definition;
insert into t_ds_task_definitionselect id,       code,       name,       version,       description,       project_code,       user_id,       task_type,       task_params,       flag,       task_priority,       worker_group,       environment_code,       fail_retry_times,       fail_retry_interval,       timeout_flag,       timeout_notify_strategy,       timeout,       delay_time,       resource_ids,       task_group_id,       task_group_priority,       create_time,       update_timefrom dolphin201.t_ds_task_definition;
###任务定义日志truncate table t_ds_task_definition_log;
insert into t_ds_task_definition_logselect t5.id,       t5.code,       t5.name,       t5.version,       t5.description,       t5.project_code,       t5.user_id,       t5.task_type,       t5.task_params,       t5.flag,       t5.task_priority,       t5.worker_group,       t5.environment_code,       t5.fail_retry_times,       t5.fail_retry_interval,       t5.timeout_flag,       t5.timeout_notify_strategy,       t5.timeout,       t5.delay_time,       t5.resource_ids,       t5.operator,       t5.task_group_id,       t5.task_group_priority,       t5.operate_time,       t5.create_time,       t5.update_timefrom dolphin201.t_ds_task_definition_log t5;
###定时计划truncate table t_ds_schedules;
insert into t_ds_schedulesselect id,       process_definition_code,       start_time,       end_time,       timezone_id,       crontab,       failure_strategy,       user_id,       '0' AS release_state,       warning_type,       warning_group_id,       process_instance_priority,       worker_group,       environment_code,       create_time,       update_timefrom dolphin201.t_ds_schedules;
###告警组 truncate table t_ds_alertgroup;
 insert into t_ds_alertgroup select id,        alert_instance_ids,        create_user_id,        group_name,        description,        create_time,        update_time from dolphin201.t_ds_alertgroup;
## ###告警组信息  ，这张表信息有冲突故不导入，后续自己配置下# truncate table t_ds_alert_plugin_instance;
# insert into t_ds_alert_plugin_instance# select id, plugin_define_id, plugin_instance_params, create_time, update_time, instance_name# from dolphin201.t_ds_alert_plugin_instance;
###用户truncate table t_ds_user;
insert into t_ds_userselect id,       user_name,       user_password,       user_type,       email,       phone,       tenant_id,       create_time,       update_time,       queue,       state,       time_zonefrom dolphin201.t_ds_user;
###租户truncate table t_ds_tenant;
insert into t_ds_tenantselect id,       tenant_code,       description,       queue_id,       create_time,       update_timefrom dolphin201.t_ds_tenant;

####资源中心truncate table t_ds_resources;
insert into t_ds_resourcesselect id,       alias,       file_name,       description,       user_id,       type,       size,       create_time,       update_time,       pid,       full_name,       is_directoryfrom dolphin201.t_ds_resources;

####数据源truncate table t_ds_datasource;
insert into t_ds_datasourceselect id,       name,       note,       type,       user_id,       connection_params,       create_time,       update_timefrom dolphin201.t_ds_datasource;

###环境情况truncate table t_ds_environment;
insert into t_ds_environmentselect id,       code,       name,       config,       description,       operator,       create_time,       update_timefrom dolphin201.t_ds_environment;
