Ascend 的 aclgraph（九）e2e 执行 aclgraph
作者：zjun
- 2025-05-19 上海
本文字数：22995 字
阅读完需：约 75 分钟
1 回顾
前面的几章内容探讨了 aclgraph 运行过程中的涉及到的关键模块和技术。本章节将前面涉及到的模块串联起来，对 aclgraph 形成一个端到端的了解。先给出端到端运行的代码，如下：
import torchimport torch_npuimport torchairimport loggingfrom torchair import loggerlogger.setLevel(logging.INFO)torch._logging.set_logs(dynamo=logging.DEBUG,aot=logging.DEBUG,output_code=True,graph_code=True)
# Patch方式实现集合通信入图（可选）from torchair import patch_for_hcompatch_for_hcom()
# 定义模型Modelclass Model(torch.nn.Module): def __init__(self): super().__init__() def forward(self, x, y): return torch.add(x, y)
# 实例化模型modelmodel = Model().npu()
# 获取TorchAir提供的默认npu backend，自行配置config功能config = torchair.CompilerConfig()config.mode = "reduce-overhead"npu_backend = torchair.get_npu_backend(compiler_config=config) // 关注点1
# 使用npu backend进行compileopt_model = torch.compile(model, backend=npu_backend) // 关注点2
# 使用编译后的model去执行x = torch.randn(2, 2).npu()y = torch.randn(2, 2).npu()out = opt_model(x, y) // 关注点3pring(out)
复制代码
config.mode = "reduce-overhead"配置了 aclgraph 的模式。该代码在 CANN8.1rc1（https://www.hiascend.com/document/detail/zh/canncommercial/81RC1/quickstart/index/index.html），torch_npu 插件版本 7.0.0（https://www.hiascend.com/document/detail/zh/Pytorch/700/configandinstg/instg/insg_0004.html）以后的版本上 aclgraph 模式才得以支持，是可以运行起来的。
关注上述代码的 3 个主要部分。
2 torchair.get_npu_backend
def get_npu_backend(*, compiler_config: CompilerConfig = None, custom_decompositions: Dict = {}): if compiler_config is None: compiler_config = CompilerConfig()
decompositions = get_npu_default_decompositions() decompositions.update(custom_decompositions)
add_npu_patch(decompositions, compiler_config)
return functools.partial(_npu_backend, compiler_config=compiler_config, decompositions=decompositions)
复制代码
从Ascend的aclgraph（一）aclgraph是什么？torchair又是怎么成图的？中可知。该函数最终返回的是_npu_backend在固定参数compiler_config和decompositions下返回的一个新的函数。
def _npu_backend(gm: torch.fx.GraphModule, example_inputs: List[torch.Tensor], compiler_config: CompilerConfig = None, decompositions: Dict = {}): if compiler_config is None: compiler_config = CompilerConfig() compiler = get_compiler(compiler_config)
input_dim_gears = dict() for i, t in enumerate(example_inputs): dim_gears = get_dim_gears(t) if dim_gears is not None: input_dim_gears[i - len(example_inputs)] = dim_gears
fw_compiler, inference_compiler, joint_compiler = _wrap_compiler(compiler, compiler_config) fw_compiler = _set_gear_to_compiler(fw_compiler, compiler_config, input_dim_gears) inference_compiler = _set_gear_to_compiler(inference_compiler, compiler_config, input_dim_gears)
partition_fn = _get_partition_fn(compiler_config) if compiler_config.experimental_config.aot_config_enable_joint_graph: output_loss_index = int(compiler_config.experimental_config.aot_config_output_loss_index.value) return aot_module_simplified_joint(gm, example_inputs, compiler=joint_compiler, decompositions=decompositions, output_loss_index=output_loss_index)
keep_inference_input_mutations = bool(compiler_config.experimental_config.keep_inference_input_mutations) # TO DO: fix me in master if compiler_config.mode.value == "reduce-overhead": keep_inference_input_mutations = False logger.debug(f"To temporarily avoid some precision problem in AclGraph, " f"keep_inference_input_mutations config is set to {keep_inference_input_mutations}.")
return aot_module_simplified(gm, example_inputs, fw_compiler=fw_compiler, bw_compiler=compiler, decompositions=decompositions, partition_fn=partition_fn, keep_inference_input_mutations=keep_inference_input_mutations, inference_compiler=inference_compiler)
复制代码
_npu_backend中最终返回的是aot_module_simplified。_npu_backend 的解析请参照Ascend的aclgraph（一）aclgraph是什么？torchair又是怎么成图的？和Ascend的aclgraph（二）_npu_backend中还有些什么秘密？。aot_module_simplified 作用在前文中可知是：通常用于简化将一个 PyTorch 模型准备好进行 AOT 编译的过程，简单理解就是 AOT 编译前的预操作。写个示例：
import torchfrom torch.compile import aot_module_simplified
# 假设有一个简单的模型class SimpleModel(torch.nn.Module): def forward(self, x): return torch.relu(x)
model = SimpleModel()
# 使用 aot_module_simplified 进行 AOT 编译compiled_model = aot_module_simplified(model)
# 现在可以使用 compiled_model 进行推理input_tensor = torch.randn(5)output_tensor = compiled_model(input_tensor)print(output_tensor)
复制代码
在这个示例中，compiled_model 就是经过 aot_module_simplified 编译优化后的模型。你可以像使用普通 PyTorch 模型那样调用它的方法来进行推理。回到代码中的关注 1，那么 npu_backend 返回的就是一个可以执行的 model 对象torch.nn.Module接着看关注 2。
3 torch.compile(model, backend=npu_backend)
通过Ascend的aclgraph（二）_npu_backend中还有些什么秘密？可知 backend 是一个回调函数（可调用的对象）
def _optimize( rebuild_ctx: Callable[[], Union[OptimizeContext, _NullDecorator]], backend="inductor", *, nopython=False, guard_export_fn=None, guard_fail_fn=None, disable=False, dynamic=None,) -> Union[OptimizeContext, _NullDecorator]: # 中间代码省略... return _optimize_catch_errors( convert_frame.convert_frame(backend, hooks=hooks), // backend，回调函数 hooks, backend_ctx_ctor, dynamic=dynamic, compiler_config=backend.get_compiler_config() if hasattr(backend, "get_compiler_config") else None, rebuild_ctx=rebuild_ctx, ) # --------------------------------------------------------------------------------------------------------------------------------------- def _optimize_catch_errors( compile_fn, hooks: Hooks, backend_ctx_ctor=null_context, export=False, dynamic=None, compiler_config=None, rebuild_ctx=None,): return OptimizeContext( convert_frame.catch_errors_wrapper(compile_fn, hooks), // 回调函数 backend_ctx_ctor=backend_ctx_ctor, first_ctx=True, export=export, dynamic=dynamic, compiler_config=compiler_config, rebuild_ctx=rebuild_ctx, )
复制代码
上述这些 ，都是 pytorch 代码中的标准流程。在 npu 上却有些不一样。
3.1 npu 上的 torch._dynamo.optimize
首先还是从代码 torch.compile 开始
def compile(model: Optional[Callable] = None, *, # Module/function to optimize fullgraph: builtins.bool = False, #If False (default), torch.compile attempts to discover compileable regions in the function that it will optimize. If True, then we require that the entire function be capturable into a single graph. If this is not possible (that is, if there are graph breaks), then this will raise an error. dynamic: Optional[builtins.bool] = None, # dynamic shape backend: Union[str, Callable] = "inductor", # backend to be used mode: Union[str, None] = None, # Can be either "default", "reduce-overhead", "max-autotune" or "max-autotune-no-cudagraphs" options: Optional[Dict[str, Union[str, builtins.int, builtins.bool]]] = None, # A dictionary of options to pass to the backend. Some notable ones to try out are disable: builtins.bool = False) # Turn torch.compile() into a no-op for testing -> Callable: # 中间代码省略... return torch._dynamo.optimize(backend=backend, nopython=fullgraph, dynamic=dynamic, disable=disable)(model)
复制代码
compile 中调用的是torch._dynamo.optimize函数。而 npu 上的torch._dynamo.optimize是被重新赋值的。函数调用流程如下：
def patch_dynamo_optimize(): src_optimize = optimize
def npu_optimize(*args, **kwargs): backend = None if 'backend' in kwargs.keys(): backend = kwargs['backend'] elif len(args) == 1: backend = args[0]
backend_name = None if isinstance(backend, str): backend_name = backend elif isinstance(backend, _TorchCompileWrapper): backend_name = backend.compiler_name
if backend_name == 'npu': # Init torchair ahead of running model. _get_global_npu_backend() return src_optimize(*args, **kwargs) torch._dynamo.optimize = npu_optimize
复制代码
可以看到，torch._dynamo.optimize = npu_optimize已经被重新赋值了。依旧从代码的角度，看下是如何一步步执行下去的。_get_global_npu_backend返回的是torchair.get_npu_backend()获取的对象，和关注点 1 加粗样式调用的接口相同，但是这里却是没有传入 congfig 参数，一切都是默认的。
def _get_global_npu_backend(): global _global_npu_backend if _global_npu_backend is not None: return _global_npu_backend if 'torchair' not in sys.modules: raise AssertionError("Could not find module torchair. " "Please check if torchair is removed from sys.modules." + pta_error(ErrCode.NOT_FOUND)) import torchair _global_npu_backend = torchair.get_npu_backend() return _global_npu_backend
复制代码
接下来调用的函数是src_optimize，而src_optimize是通过_dynamo.py 中的optimize赋值的。
src_optimize = optimize
复制代码
看下完整的 optimize 函数
def optimize( backend="inductor", *, nopython=False, guard_export_fn=None, guard_fail_fn=None, disable=False, dynamic=None,): """ The main entrypoint of TorchDynamo. Do graph capture and call backend() to optimize extracted graphs.
Args: backend: One of the two things: - Either, a function/callable taking a torch.fx.GraphModule and example_inputs and returning a python callable that runs the graph faster. One can also provide additional context for the backend, like torch.jit.fuser("fuser2"), by setting the backend_ctx_ctor attribute. See AOTAutogradMemoryEfficientFusionWithContext for the usage. - Or, a string backend name in `torch._dynamo.list_backends()` nopython: If True, graph breaks will be errors and there will be a single whole-program graph. disable: If True, turn this decorator into a no-op dynamic: If True, upfront compile as dynamic a kernel as possible. If False, disable all dynamic shapes support (always specialize). If None, automatically detect when sizes vary and generate dynamic kernels upon recompile.
Example Usage::
@torch._dynamo.optimize() def toy_example(a, b): ... """
复制代码
其中 backend 的注释
backend：可以是以下两种情况之一：
要么，它是一个函数或可调用对象，接收一个 torch.fx.GraphModule 和 example_inputs，并返回一个能够更快执行该计算图的 Python 可调用对象。你也可以通过设置 backend_ctx_ctor 属性，为 backend 提供额外的上下文信息，例如：torch.jit.fuser("fuser2")。使用方式请参见：AOTAutogradMemoryEfficientFusionWithContext。
要么，它是一个字符串，表示后端名称，这个名称必须在 torch._dynamo.list_backends() 返回的列表中。
当前 npu 下，属于第一种情况的 backend。补充完整调用栈：
optimize最终使能到的对象是_TorchDynamoContext。torch._dynamo.optimize的流程就走完了。再回到
return torch._dynamo.optimize(backend=backend, nopython=fullgraph, dynamic=dynamic, disable=disable)(model)
复制代码
关注最后一个参数 model，意思也就是给_TorchDynamoContext传入参数 model，会触发调用_TorchDynamoContext的__call__方法。由于例子中的 Model()是个 fn, torch.nn.Module 对象，因此走到下面的代码分支
... 省略if isinstance(fn, torch.nn.Module): mod = fn new_mod = OptimizedModule(mod, self) # Save the function pointer to find the original callable while nesting # of decorators. new_mod._torchdynamo_orig_callable = mod.forward
# when compiling torch.nn.Module, # provide public api OptimizedModule.get_compiler_config() assert not hasattr(new_mod, "get_compiler_config") new_mod.get_compiler_config = get_compiler_config
return new_mod... 省略
复制代码
返回的是一个OptimizedModule实例对象。
new_mod = OptimizedModule(mod, self)
复制代码
特别要注意OptimizedModule对象，实例创建的过程其实包含一段执行逻辑，先看流程图
再给出代码：
class OptimizedModule(torch.nn.Module): """ Wraps the original nn.Module object and later patches its forward method to optimized self.forward method. """
_torchdynamo_orig_callable: Callable[..., Any] get_compiler_config: Callable[[], Any]
def __init__(self, mod: torch.nn.Module, dynamo_ctx): super().__init__() # Installs the params/buffer self._orig_mod = mod self.dynamo_ctx = dynamo_ctx self._initialize()
def _initialize(self): # Do this stuff in constructor to lower overhead slightly if isinstance(self._orig_mod.forward, types.MethodType) and trace_rules.check( self._orig_mod.forward ): # This may be a torch.nn.* instance in trace_rules.py which # won't trigger a frame evaluation workaround to add an extra # frame we can capture self.forward = self.dynamo_ctx(external_utils.wrap_inline(self._orig_mod)) else: # Invoke hooks outside of dynamo then pickup the inner frame self.forward = self.dynamo_ctx(self._orig_mod.__call__)
if hasattr(self._orig_mod, "_initialize_hook"): self._forward = self.forward self.forward = self._call_lazy_check
复制代码
而self.forward = self.dynamo_ctx(self._orig_mod.__call__)这行代码会去执行_TorchDynamoContext原的__call__函数的，逻辑是如下。OptimizedModule 的构造函数种，mod 就是传入的mode对象，而 dynamo_ctx 是_TorchDynamoContext。
self._orig_mod = modself.dynamo_ctx = dynamo_ctx
复制代码
那么self.dynamo_ctx(self._orig_mod.__call__)，意思也就是调用_TorchDynamoContext的__call__函数，然后参数是 mode 的__call__对象。也就是说，_TorchDynamoContext的__call__函数被执行了 2 遍。最终__call__函数返回的是_fn函数。
@functools.wraps(fn)def _fn(*args, **kwargs): if is_fx_tracing(): if config.error_on_nested_fx_trace: raise RuntimeError( "Detected that you are using FX to symbolically trace " "a dynamo-optimized function. This is not supported at the moment." ) else: return fn(*args, **kwargs)
if is_jit_tracing(): if config.error_on_nested_jit_trace: raise RuntimeError( "Detected that you are using FX to torch.jit.trace " "a dynamo-optimized function. This is not supported at the moment." ) else: return fn(*args, **kwargs)
cleanups = [enter() for enter in self.enter_exit_hooks] prior = set_eval_frame(callback) try: return fn(*args, **kwargs) finally: set_eval_frame(prior) for cleanup in cleanups: cleanup()
always_optimize_code_objects[fn.__code__] = True
... 省略 ...
return _fn
复制代码
读到这里，也就是说torch.compile返回的就是_fn函数。
4 opt_model(x, y)
现在走到关注点 3，到模型执行部分，调用的是_fn函数，
@functools.wraps(fn)def _fn(*args, **kwargs): if is_fx_tracing(): if config.error_on_nested_fx_trace: raise RuntimeError( "Detected that you are using FX to symbolically trace " "a dynamo-optimized function. This is not supported at the moment." ) else: return fn(*args, **kwargs)
if is_jit_tracing(): if config.error_on_nested_jit_trace: raise RuntimeError( "Detected that you are using FX to torch.jit.trace " "a dynamo-optimized function. This is not supported at the moment." ) else: return fn(*args, **kwargs)
cleanups = [enter() for enter in self.enter_exit_hooks] prior = set_eval_frame(callback) try: return fn(*args, **kwargs) finally: set_eval_frame(prior) for cleanup in cleanups: cleanup()
复制代码
函数种fn是 Model对象
<bound method Module._wrapped_call_impl of Model()>
复制代码
接下来执行的时候，会触发回调函数的调用。具体是如何触发的呢？首先是：prior = set_eval_frame(callback)，这句代码的意思，就是给 frame 设置了 callback 函数，该 callback 函数是convert_frame.convert_frame(backend, hooks=hooks)，具体参见：Ascend的aclgraph（三）TorchDynamo。
4.1 设置 set_eval_frame 的 callback
set_eval_frame是个 pybind 函数，最终执行调用的是 c++（pytorch/torch/csrc/dynamo/eval_frame.c）的是set_eval_frame函数，
static PyObject* set_eval_frame( PyObject* new_callback, PyThreadState* tstate, PyObject* module) { // Change the eval frame callback and return the old one // - None: disables TorchDynamo // - False: run-only mode (reuse existing compiles) // - Python callable(): enables TorchDynamo PyObject* old_callback = eval_frame_callback_get();
// owned by caller Py_INCREF(old_callback);
if (old_callback != Py_None && new_callback == Py_None) { decrement_working_threads(tstate, module); } else if (old_callback == Py_None && new_callback != Py_None) { increment_working_threads(tstate, module); }
Py_INCREF(new_callback); Py_DECREF(old_callback);
// Set thread local callback. This will drive behavior of our shim, if/when it // is installed. eval_frame_callback_set(new_callback);
return old_callback;}
复制代码
接着调用eval_frame_callback_set，
void eval_frame_callback_set(PyObject* obj) { PyThread_tss_set(&eval_frame_callback_key, obj);}
复制代码
PyThread_tss_set可以认为是eval_frame_callback_key是key，obj是value。eval_frame_callback_key是个静态全局变量。
4.2 执行 fn(*args, **kwargs)
Ascend的aclgraph（三）TorchDynamo中有提到，通过 CPython 提供的_PyInterpreterState_SetEvalFrameFunc()函数把 CPython 中用于执行字节码的默认函数给替换为custom_eval_frame_shim()。 在执行用户想要编译的函数时便会进入_custom_eval_frame_shim().注意：小编看的代码中是dynamo_custom_eval_frame_shim（因为版本原因，小编是最新的 main 分支）。整体逻辑如下：
最终调用执行的函数就是dynamo__custom_eval_frame。该函数在https://github.com/pytorch/pytorch/blob/main/torch/csrc/dynamo/eval_frame_cpp.cpp中实现，如下：
/ frame and callback are borrowed references.// Returns new reference.PyObject* dynamo__custom_eval_frame( PyThreadState* tstate, THP_EVAL_API_FRAME_OBJECT* frame, int throw_flag, PyObject* callback_py) {#if IS_PYTHON_3_11_PLUS DEBUG_TRACE( "begin %s %s %i %i", get_frame_name(frame), PyUnicode_AsUTF8(F_CODE(frame)->co_filename), F_CODE(frame)->co_firstlineno, _PyInterpreterFrame_LASTI(frame));#else DEBUG_TRACE( "begin %s %s %i %i %i", get_frame_name(frame), PyUnicode_AsUTF8(F_CODE(frame)->co_filename), frame->f_lineno, frame->f_lasti, frame->f_iblock);#endif
if (throw_flag) { // When unwinding generators, eval frame is called with throw_flag == // true. Frame evaluation is supposed to continue unwinding by propagating // the exception. Dynamo doesn't really know how to do this, nor does it // really want to do this, because there's unlikely any code to capture // (you're going to immediately quit out of the frame, perhaps running // some unwinding logic along the way). So we just run the default // handler in this case. // // NB: A previous version of this patch returned NULL. This is wrong, // because returning NULL is *different* from unwinding an exception. // In particular, you will not execute things like context manager // __exit__ if you just return NULL. // // NB: It's /conceivable/ that you might want to actually still call the // Dynamo callback when throw_flag == TRUE, to give Dynamo a chance to // do any stack unwinding code. But this is not really useful because // (1) Dynamo doesn't actually know how to do stack unwinding, so it would // immediately skip the frame, and (2) even if it did, this would only // be profitable if there was tensor code in the unwinding code. Seems // unlikely. DEBUG_TRACE("throw %s", get_frame_name(frame)); return dynamo_eval_frame_default(tstate, frame, throw_flag); }
py::handle callback(callback_py);
// callback to run on recursively invoked frames py::handle recursive_callback = callback; // borrowed PyCodeObject* cached_code = nullptr; // borrowed const char* trace_annotation = ""; PyObject* eval_result = nullptr; // strong reference
// exit functions auto eval_default = [&]() { eval_frame_callback_set(recursive_callback.ptr()); eval_result = dynamo_eval_frame_default(tstate, frame, throw_flag); if (!callback.is(recursive_callback)) { // NB: Only set the callback if it's different than the recursive // callback! Setting the callback is dangerous in the case that `frame` // also sets the eval frame callback. This happens in some functions in // eval_frame.py. These functions should be skipped with DEFAULT recursive // action, so we won't accidentally overwrite the callback. eval_frame_callback_set(callback.ptr()); } };
// NOTE: In 3.12+, the frame evaluation function (callee) is responsible for // clearing/popping the frame, meaning that unless we default evaluate the // original frame, we are responsible for clearing it - via // clear_old_frame_if_python_312_plus. auto eval_custom = [&]() { eval_frame_callback_set(recursive_callback.ptr()); DEBUG_NULL_CHECK(cached_code); eval_result = dynamo_eval_custom_code( tstate, frame, cached_code, trace_annotation, throw_flag); if (!callback.is(recursive_callback)) { eval_frame_callback_set(callback.ptr()); } clear_old_frame_if_python_312_plus(tstate, frame); };
auto fail = [&]() { clear_old_frame_if_python_312_plus(tstate, frame); };
ExtraState* extra = get_extra_state(F_CODE(frame));
if (callback.is(py::bool_(false)) && extra == nullptr) { DEBUG_TRACE("skip (run only with empty cache) %s", get_frame_name(frame)); eval_default(); return eval_result; }
// create cache if (extra == nullptr) { extra = init_and_set_extra_state(F_CODE(frame)); }
// Get recursive action FrameExecStrategy strategy = extra_state_get_exec_strategy(extra); recursive_callback = _callback_from_action(recursive_callback, strategy.recursive_action);
// Skip this frame if (strategy.cur_action == SKIP) { DEBUG_TRACE("skip %s", get_frame_name(frame)); eval_default(); return eval_result; }
// default and run-only mode require guard eval std::unique_ptr<FrameLocalsMapping> locals = std::make_unique<FrameLocalsMapping>(frame); PyObject* backend = get_backend(callback.ptr()); // borrowed
// We don't run the current custom_eval_frame behavior for guards. // So we temporarily set the callback to Py_None to drive the correct behavior // in the shim. eval_frame_callback_set(Py_None);
DEBUG_CHECK(PyDict_CheckExact(frame->f_globals)); DEBUG_CHECK(PyDict_CheckExact(frame->f_builtins));
_PytorchRecordFunctionState* rf = _pytorch_record_function_enter(cache_lookup_profiler_str); PyObject* maybe_cached_code = nullptr; lookup( extra, locals.get(), backend, &maybe_cached_code, &trace_annotation, is_skip_guard_eval_unsafe); _pytorch_record_function_exit(rf);
// A callback of Py_False indicates "run only" mode, the cache is checked, // but we never compile. bool run_only = strategy.cur_action == RUN_ONLY || callback.is(py::bool_(false)); if (run_only) { DEBUG_TRACE("In run only mode %s", get_frame_name(frame)); }
if (maybe_cached_code == nullptr) { // guard eval failed, keep propagating fail(); return eval_result; } else if (maybe_cached_code != Py_None) { cached_code = (PyCodeObject*)maybe_cached_code; // used cached version DEBUG_TRACE("cache hit %s", get_frame_name(frame)); eval_custom(); return eval_result; }
// cache miss DEBUG_TRACE("cache miss %s", get_frame_name(frame)); if (is_skip_guard_eval_unsafe) { PyErr_SetString( PyExc_RuntimeError, "Recompilation triggered with skip_guard_eval_unsafe stance. " "This usually means that you have not warmed up your model " "with enough inputs such that you can guarantee no more recompilations."); fail(); return eval_result; }
if (run_only) { eval_default(); return eval_result; }
// call callback CacheEntry* cache_entry = extract_cache_entry(extra); FrameState* frame_state = extract_frame_state(extra); py::object callback_result; FrameExecStrategy new_strategy; bool apply_to_code = false; PyObject* guarded_code = nullptr; try { callback_result = dynamo_call_callback( callback, frame, locals.get(), cache_entry, frame_state); new_strategy = callback_result.attr("frame_exec_strategy").cast<FrameExecStrategy>(); apply_to_code = callback_result.attr("apply_to_code").cast<bool>(); guarded_code = callback_result.attr("guarded_code").ptr(); } catch (py::error_already_set& e) { // internal exception, returning here will leak the exception into user // code this is useful for debugging -- but we dont want it to happen // outside of testing NB: we intentionally DO NOT re-enable custom // behavior to prevent cascading failure from internal exceptions. The // upshot is if Dynamo barfs, that's it for Dynamo, even if you catch the // exception inside the torch.compile block we won't try to Dynamo // anything else. fail(); e.restore(); return eval_result; }
// recursive frame action if (strategy.recursive_action == DEFAULT) { // old recursive action overrides new recursive action recursive_callback = _callback_from_action( recursive_callback, new_strategy.recursive_action); }
// possibly apply frame strategy to future frames with same code object if (apply_to_code) { if (new_strategy.cur_action != DEFAULT) { DEBUG_TRACE("create action: %d\n", new_strategy.cur_action); } if (new_strategy.recursive_action != DEFAULT) { DEBUG_TRACE( "create recursive action: %d\n", new_strategy.recursive_action); } extra_state_set_exec_strategy(extra, new_strategy); }
if (guarded_code != Py_None) { DEBUG_TRACE("create cache %s", get_frame_name(frame));
// NB: We could use extract_cache_entry to get the cache_entry, but // extract_cache_entry returns a borrowed reference. Modifying a borrowed // reference seems wrong. Therefore, we directly access the // extra->cache_entry. extra wont be NULL here. CacheEntry* new_cache_entry = create_cache_entry(extra, guarded_code, backend);
// Update the existing cache_entry on the extra object. This extra object // is sitting on the extra scratch space, we are just changing the // cache_entry ptr. As a result, extra now becomes the owner of CacheEntry // object. This will be cleaned up when set_extra_state is called. // Re-enable custom behavior cached_code = CacheEntry_get_code(new_cache_entry), trace_annotation = CacheEntry_get_trace_annotation(new_cache_entry); eval_custom(); } else { eval_default(); } return eval_result;}
复制代码
整个函数很长，但基本逻辑与Ascend的aclgraph（三）TorchDynamo中讲的一样，这里引用过来：
在_custom_eval_frame 函数中，会先通过 lookup 函数检查 cache 中是否有已编译代码，若存在则直接调用 eval_custom_code 函数执行，从而避免重复编译相同函数。若 cache 未命中，则通过 call_callback 调用回调函数进行编译，并通过 set_extra()将编译结果保存在 PyFrameObject 中，最后调用 eval_custom_code 继续进行执行。而这里的回调函数也即前面在 torch._dynamo.optimize 传入的回调函数：convert_frame.convert_frame(backend, hooks=hooks)（包含编译入口 compile_fn）。
打开日志可以看到具体的编译过程。
V0515 09:03:05.795000 281473434236992 torch/_dynamo/convert_frame.py:254] skipping because no torch.* dispatch_call /usr/local/python3.10.17/lib/python3.10/bdb.py 118V0515 09:03:05.795000 281473434236992 torch/_dynamo/convert_frame.py:254] skipping because no torch.* break_anywhere /usr/local/python3.10.17/lib/python3.10/bdb.py 251V0515 09:03:05.802000 281473434236992 torch/_dynamo/convert_frame.py:652] [0/0] torchdynamo start compiling forward /home/torchair/test.py:19, stack (elided 5 frames):V0515 09:03:05.802000 281473434236992 torch/_dynamo/convert_frame.py:652] [0/0] File "/home/torchair/test.py", line 37, in <module>V0515 09:03:05.802000 281473434236992 torch/_dynamo/convert_frame.py:652] [0/0] print(opt_model(x, y))V0515 09:03:05.802000 281473434236992 torch/_dynamo/convert_frame.py:652] [0/0] File "/usr/local/python3.10.17/lib/python3.10/site-packages/torch/nn/modules/module.py", line 1532, in _wrapped_call_implV0515 09:03:05.802000 281473434236992 torch/_dynamo/convert_frame.py:652] [0/0] return self._call_impl(*args, **kwargs)V0515 09:03:05.802000 281473434236992 torch/_dynamo/convert_frame.py:652] [0/0] File "/usr/local/python3.10.17/lib/python3.10/site-packages/torch/nn/modules/module.py", line 1541, in _call_implV0515 09:03:05.802000 281473434236992 torch/_dynamo/convert_frame.py:652] [0/0] return forward_call(*args, **kwargs)V0515 09:03:05.802000 281473434236992 torch/_dynamo/convert_frame.py:652] [0/0] File "/usr/local/python3.10.17/lib/python3.10/site-packages/torch/_dynamo/eval_frame.py", line 451, in _fnV0515 09:03:05.802000 281473434236992 torch/_dynamo/convert_frame.py:652] [0/0] return fn(*args, **kwargs)V0515 09:03:05.802000 281473434236992 torch/_dynamo/convert_frame.py:652] [0/0] File "/usr/local/python3.10.17/lib/python3.10/site-packages/torch/nn/modules/module.py", line 1532, in _wrapped_call_implV0515 09:03:05.802000 281473434236992 torch/_dynamo/convert_frame.py:652] [0/0] return self._call_impl(*args, **kwargs)V0515 09:03:05.802000 281473434236992 torch/_dynamo/convert_frame.py:652] [0/0] File "/usr/local/python3.10.17/lib/python3.10/site-packages/torch/nn/modules/module.py", line 1541, in _call_implV0515 09:03:05.802000 281473434236992 torch/_dynamo/convert_frame.py:652] [0/0] return forward_call(*args, **kwargs)V0515 09:03:05.802000 281473434236992 torch/_dynamo/convert_frame.py:652] [0/0] I0515 09:03:05.806000 281473434236992 torch/_dynamo/logging.py:55] [0/0] Step 1: torchdynamo start tracing forward /home/torchair/test.py:19V0515 09:03:05.809000 281473434236992 torch/fx/experimental/symbolic_shapes.py:1980] [0/0] create_envV0515 09:03:05.814000 281473434236992 torch/_dynamo/symbolic_convert.py:699] [0/0] [__trace_source] TRACE starts_line /home/torchair/test.py:19 in forward (Model.forward)V0515 09:03:05.814000 281473434236992 torch/_dynamo/symbolic_convert.py:699] [0/0] [__trace_source] def forward(self, x, y):V0515 09:03:07.619000 281473434236992 torch/_dynamo/symbolic_convert.py:699] [0/0] [__trace_source] TRACE starts_line /home/torchair/test.py:20 in forward (Model.forward)V0515 09:03:07.619000 281473434236992 torch/_dynamo/symbolic_convert.py:699] [0/0] [__trace_source] return torch.add(x, y)V0515 09:03:07.620000 281473434236992 torch/_dynamo/symbolic_convert.py:725] [0/0] TRACE LOAD_GLOBAL torch []V0515 09:03:07.622000 281473434236992 torch/_dynamo/symbolic_convert.py:725] [0/0] TRACE LOAD_ATTR add [PythonModuleVariable(<module 'torch' from '/usr/local/python3.10.17/lib/python3.10/site-packages/torch/__init__.py'>)]V0515 09:03:07.625000 281473434236992 torch/_dynamo/symbolic_convert.py:725] [0/0] TRACE LOAD_FAST x [TorchInGraphFunctionVariable(<built-in method add of type object at 0xffffa30bf048>)]V0515 09:03:07.625000 281473434236992 torch/_dynamo/symbolic_convert.py:725] [0/0] TRACE LOAD_FAST y [TorchInGraphFunctionVariable(<built-in method add of type object at 0xffffa30bf048>), LazyVariableTracker()]V0515 09:03:07.626000 281473434236992 torch/_dynamo/symbolic_convert.py:725] [0/0] TRACE CALL_FUNCTION 2 [TorchInGraphFunctionVariable(<built-in method add of type object at 0xffffa30bf048>), LazyVariableTracker(), LazyVariableTracker()]V0515 09:03:07.627000 281473434236992 torch/_dynamo/output_graph.py:1959] [0/0] create_graph_input L_x_ L['x']V0515 09:03:07.629000 281473434236992 torch/_dynamo/variables/builder.py:1873] [0/0] wrap_to_fake L['x'] (2, 2) StatefulSymbolicContext(dynamic_sizes=[<DimDynamic.STATIC: 2>, <DimDynamic.STATIC: 2>], constraint_sizes=[None, None], view_base_context=None, tensor_source=LocalSource(local_name='x', cell_or_freevar=False), shape_env_to_source_to_symbol_cache={}) <class 'torch.Tensor'>V0515 09:03:07.635000 281473434236992 torch/_dynamo/output_graph.py:1959] [0/0] create_graph_input L_y_ L['y']V0515 09:03:07.636000 281473434236992 torch/_dynamo/variables/builder.py:1873] [0/0] wrap_to_fake L['y'] (2, 2) StatefulSymbolicContext(dynamic_sizes=[<DimDynamic.STATIC: 2>, <DimDynamic.STATIC: 2>], constraint_sizes=[None, None], view_base_context=None, tensor_source=LocalSource(local_name='y', cell_or_freevar=False), shape_env_to_source_to_symbol_cache={}) <class 'torch.Tensor'>V0515 09:03:07.645000 281473434236992 torch/_dynamo/symbolic_convert.py:725] [0/0] TRACE RETURN_VALUE None [TensorVariable()]I0515 09:03:07.645000 281473434236992 torch/_dynamo/logging.py:55] [0/0] Step 1: torchdynamo done tracing forward (RETURN_VALUE)V0515 09:03:07.646000 281473434236992 torch/_dynamo/symbolic_convert.py:2267] [0/0] RETURN_VALUE triggered compileV0515 09:03:07.646000 281473434236992 torch/_dynamo/output_graph.py:871] [0/0] COMPILING GRAPH due to GraphCompileReason(reason='return_value', user_stack=[<FrameSummary file /home/torchair/test.py, line 20 in forward>], graph_break=False)V0515 09:03:07.649000 281473434236992 torch/_dynamo/output_graph.py:1157] [0/0] [__graph_code] TRACED GRAPHV0515 09:03:07.649000 281473434236992 torch/_dynamo/output_graph.py:1157] [0/0] [__graph_code] ===== __compiled_fn_0 =====V0515 09:03:07.649000 281473434236992 torch/_dynamo/output_graph.py:1157] [0/0] [__graph_code] /usr/local/python3.10.17/lib/python3.10/site-packages/torch/fx/_lazy_graph_module.py class GraphModule(torch.nn.Module):V0515 09:03:07.649000 281473434236992 torch/_dynamo/output_graph.py:1157] [0/0] [__graph_code] def forward(self, L_x_ : torch.Tensor, L_y_ : torch.Tensor):V0515 09:03:07.649000 281473434236992 torch/_dynamo/output_graph.py:1157] [0/0] [__graph_code] l_x_ = L_x_V0515 09:03:07.649000 281473434236992 torch/_dynamo/output_graph.py:1157] [0/0] [__graph_code] l_y_ = L_y_V0515 09:03:07.649000 281473434236992 torch/_dynamo/output_graph.py:1157] [0/0] [__graph_code] V0515 09:03:07.649000 281473434236992 torch/_dynamo/output_graph.py:1157] [0/0] [__graph_code] # File: /home/torchair/test.py:20 in forward, code: return torch.add(x, y)V0515 09:03:07.649000 281473434236992 torch/_dynamo/output_graph.py:1157] [0/0] [__graph_code] add = torch.add(l_x_, l_y_); l_x_ = l_y_ = NoneV0515 09:03:07.649000 281473434236992 torch/_dynamo/output_graph.py:1157] [0/0] [__graph_code] return (add,)V0515 09:03:07.649000 281473434236992 torch/_dynamo/output_graph.py:1157] [0/0] [__graph_code] V0515 09:03:07.649000 281473434236992 torch/_dynamo/output_graph.py:1157] [0/0] [__graph_code] V0515 09:03:07.653000 281473434236992 torch/_dynamo/output_graph.py:1163] [0/0] [__graph] Tabulate module missing, please install tabulate to log the graph in tabular format, logging code instead:V0515 09:03:07.653000 281473434236992 torch/_dynamo/output_graph.py:1163] [0/0] [__graph] TRACED GRAPHV0515 09:03:07.653000 281473434236992 torch/_dynamo/output_graph.py:1163] [0/0] [__graph] ===== __compiled_fn_0 =====V0515 09:03:07.653000 281473434236992 torch/_dynamo/output_graph.py:1163] [0/0] [__graph] /usr/local/python3.10.17/lib/python3.10/site-packages/torch/fx/_lazy_graph_module.py class GraphModule(torch.nn.Module):V0515 09:03:07.653000 281473434236992 torch/_dynamo/output_graph.py:1163] [0/0] [__graph] def forward(self, L_x_ : torch.Tensor, L_y_ : torch.Tensor):V0515 09:03:07.653000 281473434236992 torch/_dynamo/output_graph.py:1163] [0/0] [__graph] l_x_ = L_x_V0515 09:03:07.653000 281473434236992 torch/_dynamo/output_graph.py:1163] [0/0] [__graph] l_y_ = L_y_V0515 09:03:07.653000 281473434236992 torch/_dynamo/output_graph.py:1163] [0/0] [__graph] V0515 09:03:07.653000 281473434236992 torch/_dynamo/output_graph.py:1163] [0/0] [__graph] # File: /home/torchair/test.py:20 in forward, code: return torch.add(x, y)V0515 09:03:07.653000 281473434236992 torch/_dynamo/output_graph.py:1163] [0/0] [__graph] add = torch.add(l_x_, l_y_); l_x_ = l_y_ = NoneV0515 09:03:07.653000 281473434236992 torch/_dynamo/output_graph.py:1163] [0/0] [__graph] return (add,)V0515 09:03:07.653000 281473434236992 torch/_dynamo/output_graph.py:1163] [0/0] [__graph] V0515 09:03:07.653000 281473434236992 torch/_dynamo/output_graph.py:1163] [0/0] [__graph] V0515 09:03:07.656000 281473434236992 torch/_dynamo/output_graph.py:1164] [0/0] [__graph_sizes] TRACED GRAPH TENSOR SIZESV0515 09:03:07.656000 281473434236992 torch/_dynamo/output_graph.py:1164] [0/0] [__graph_sizes] ===== __compiled_fn_0 =====V0515 09:03:07.656000 281473434236992 torch/_dynamo/output_graph.py:1164] [0/0] [__graph_sizes] l_x_: (2, 2)V0515 09:03:07.656000 281473434236992 torch/_dynamo/output_graph.py:1164] [0/0] [__graph_sizes] l_y_: (2, 2)V0515 09:03:07.656000 281473434236992 torch/_dynamo/output_graph.py:1164] [0/0] [__graph_sizes] add: (2, 2)V0515 09:03:07.656000 281473434236992 torch/_dynamo/output_graph.py:1164] [0/0] [__graph_sizes] I0515 09:03:07.658000 281473434236992 torch/_dynamo/logging.py:55] [0/0] Step 2: calling compiler function functools.partial(<function _npu_backend at 0xfffddf6fedd0>, compiler_config=<torchair.configs.compiler_config.CompilerConfig object at 0xffffa3937e50>, decompositions={<OpOverload(op='npu_define.allgather', overload='default')>: <function allgather_decomposition at 0xfffddf03f130>, <OpOverload(op='_c10d_functional.all_to_all_single', overload='default')>: <function decomp_c10d_functional_all_to_all_single at 0xfffddf731510>})I0515 09:03:07.717000 281473434236992 torch/_functorch/_aot_autograd/dispatch_and_compile_graph.py:109] [0/0] [__aot_graphs] TRACED GRAPHI0515 09:03:07.717000 281473434236992 torch/_functorch/_aot_autograd/dispatch_and_compile_graph.py:109] [0/0] [__aot_graphs] ===== Forward graph 0 =====I0515 09:03:07.717000 281473434236992 torch/_functorch/_aot_autograd/dispatch_and_compile_graph.py:109] [0/0] [__aot_graphs] /usr/local/python3.10.17/lib/python3.10/site-packages/torch/fx/_lazy_graph_module.py class <lambda>(torch.nn.Module):I0515 09:03:07.717000 281473434236992 torch/_functorch/_aot_autograd/dispatch_and_compile_graph.py:109] [0/0] [__aot_graphs] def forward(self, arg0_1: "f32[2, 2]", arg1_1: "f32[2, 2]"):I0515 09:03:07.717000 281473434236992 torch/_functorch/_aot_autograd/dispatch_and_compile_graph.py:109] [0/0] [__aot_graphs] # File: /home/torchair/test.py:20 in forward, code: return torch.add(x, y)I0515 09:03:07.717000 281473434236992 torch/_functorch/_aot_autograd/dispatch_and_compile_graph.py:109] [0/0] [__aot_graphs] add: "f32[2, 2]" = torch.ops.aten.add.Tensor(arg0_1, arg1_1); arg0_1 = arg1_1 = NoneI0515 09:03:07.717000 281473434236992 torch/_functorch/_aot_autograd/dispatch_and_compile_graph.py:109] [0/0] [__aot_graphs] return (add,)I0515 09:03:07.717000 281473434236992 torch/_functorch/_aot_autograd/dispatch_and_compile_graph.py:109] [0/0] [__aot_graphs] I0515 09:03:07.717000 281473434236992 torch/_functorch/_aot_autograd/dispatch_and_compile_graph.py:109] [0/0] [__aot_graphs] [INFO] TORCHAIR(9569,python):2025-05-15 09:03:07.720.050 [npu_fx_compiler.py:324]9569 compiler inputs[INFO] TORCHAIR(9569,python):2025-05-15 09:03:07.720.361 [npu_fx_compiler.py:326]9569 input 0: FakeTensor(..., device='npu:0', size=(2, 2))[INFO] TORCHAIR(9569,python):2025-05-15 09:03:07.720.982 [npu_fx_compiler.py:326]9569 input 1: FakeTensor(..., device='npu:0', size=(2, 2))[INFO] TORCHAIR(9569,python):2025-05-15 09:03:07.721.521 [npu_fx_compiler.py:327]9569 graph: graph(): %arg0_1 : [num_users=1] = placeholder[target=arg0_1] %arg1_1 : [num_users=1] = placeholder[target=arg1_1] %add : [num_users=1] = call_function[target=torch.ops.aten.add.Tensor](args = (%arg0_1, %arg1_1), kwargs = {}) return (add,)I0515 09:03:07.745000 281473434236992 torch/_dynamo/logging.py:55] [0/0] Step 2: done compiler function functools.partial(<function _npu_backend at 0xfffddf6fedd0>, compiler_config=<torchair.configs.compiler_config.CompilerConfig object at 0xffffa3937e50>, decompositions={<OpOverload(op='npu_define.allgather', overload='default')>: <function allgather_decomposition at 0xfffddf03f130>, <OpOverload(op='_c10d_functional.all_to_all_single', overload='default')>: <function decomp_c10d_functional_all_to_all_single at 0xfffddf731510>})I0515 09:03:07.753000 281473434236992 torch/fx/experimental/symbolic_shapes.py:2806] [0/0] produce_guardsV0515 09:03:07.754000 281473434236992 torch/fx/experimental/symbolic_shapes.py:2988] [0/0] track_symint L['x'].size()[0] 2 NoneV0515 09:03:07.754000 281473434236992 torch/fx/experimental/symbolic_shapes.py:2988] [0/0] track_symint L['x'].size()[1] 2 NoneV0515 09:03:07.754000 281473434236992 torch/fx/experimental/symbolic_shapes.py:2988] [0/0] track_symint L['x'].stride()[0] 2 NoneV0515 09:03:07.755000 281473434236992 torch/fx/experimental/symbolic_shapes.py:2988] [0/0] track_symint L['x'].stride()[1] 1 NoneV0515 09:03:07.755000 281473434236992 torch/fx/experimental/symbolic_shapes.py:2988] [0/0] track_symint L['x'].storage_offset() 0 NoneV0515 09:03:07.756000 281473434236992 torch/fx/experimental/symbolic_shapes.py:2988] [0/0] track_symint L['y'].size()[0] 2 NoneV0515 09:03:07.756000 281473434236992 torch/fx/experimental/symbolic_shapes.py:2988] [0/0] track_symint L['y'].size()[1] 2 NoneV0515 09:03:07.756000 281473434236992 torch/fx/experimental/symbolic_shapes.py:2988] [0/0] track_symint L['y'].stride()[0] 2 NoneV0515 09:03:07.757000 281473434236992 torch/fx/experimental/symbolic_shapes.py:2988] [0/0] track_symint L['y'].stride()[1] 1 NoneV0515 09:03:07.757000 281473434236992 torch/fx/experimental/symbolic_shapes.py:2988] [0/0] track_symint L['y'].storage_offset() 0 NoneV0515 09:03:07.759000 281473434236992 torch/fx/experimental/symbolic_shapes.py:3138] [0/0] Skipping guard L['x'].size()[0] == 2V0515 09:03:07.759000 281473434236992 torch/fx/experimental/symbolic_shapes.py:3138] [0/0] Skipping guard L['x'].size()[1] == 2V0515 09:03:07.760000 281473434236992 torch/fx/experimental/symbolic_shapes.py:3138] [0/0] Skipping guard L['x'].stride()[0] == 2V0515 09:03:07.760000 281473434236992 torch/fx/experimental/symbolic_shapes.py:3138] [0/0] Skipping guard L['x'].stride()[1] == 1V0515 09:03:07.761000 281473434236992 torch/fx/experimental/symbolic_shapes.py:3138] [0/0] Skipping guard L['x'].storage_offset() == 0V0515 09:03:07.762000 281473434236992 torch/fx/experimental/symbolic_shapes.py:3138] [0/0] Skipping guard L['y'].size()[0] == 2V0515 09:03:07.762000 281473434236992 torch/fx/experimental/symbolic_shapes.py:3138] [0/0] Skipping guard L['y'].size()[1] == 2V0515 09:03:07.763000 281473434236992 torch/fx/experimental/symbolic_shapes.py:3138] [0/0] Skipping guard L['y'].stride()[0] == 2V0515 09:03:07.763000 281473434236992 torch/fx/experimental/symbolic_shapes.py:3138] [0/0] Skipping guard L['y'].stride()[1] == 1V0515 09:03:07.764000 281473434236992 torch/fx/experimental/symbolic_shapes.py:3138] [0/0] Skipping guard L['y'].storage_offset() == 0V0515 09:03:07.764000 281473434236992 torch/_dynamo/guards.py:1076] [0/0] [__guards] GUARDS:V0515 09:03:07.765000 281473434236992 torch/_dynamo/guards.py:1085] [0/0] [__guards] hasattr(L['x'], '_dynamo_dynamic_indices') == False # return torch.add(x, y) # ome/torchair/test.py:20 in forwardV0515 09:03:07.768000 281473434236992 torch/_dynamo/guards.py:1085] [0/0] [__guards] hasattr(L['y'], '_dynamo_dynamic_indices') == False # return torch.add(x, y) # ome/torchair/test.py:20 in forwardV0515 09:03:07.770000 281473434236992 torch/_dynamo/guards.py:1085] [0/0] [__guards] utils_device.CURRENT_DEVICE == None # _dynamo/output_graph.py:430 in init_ambient_guardsV0515 09:03:07.772000 281473434236992 torch/_dynamo/guards.py:1085] [0/0] [__guards] ___check_current_backend(281468843512288) # _dynamo/output_graph.py:436 in init_ambient_guardsV0515 09:03:07.773000 281473434236992 torch/_dynamo/guards.py:1085] [0/0] [__guards] check_tensor(L['x'], Tensor, DispatchKeySet(PrivateUse1, BackendSelect, ADInplaceOrView, AutogradPrivateUse1), torch.float32, device=0, requires_grad=False, size=[2, 2], stride=[2, 1]) # return torch.add(x, y) # ome/torchair/test.py:20 in forwardV0515 09:03:07.775000 281473434236992 torch/_dynamo/guards.py:1085] [0/0] [__guards] check_tensor(L['y'], Tensor, DispatchKeySet(PrivateUse1, BackendSelect, ADInplaceOrView, AutogradPrivateUse1), torch.float32, device=0, requires_grad=False, size=[2, 2], stride=[2, 1]) # return torch.add(x, y) # ome/torchair/test.py:20 in forward[INFO] TORCHAIR(9569,python):2025-05-15 09:03:08.055.789 [fx2acl_converter.py:148]9569 Success to capture fx graph[id: 281468755723648] and start to run AclGraph[id: 281468838205920].
复制代码
模型的最终输出：
tensor([[-1.4626, 1.1921], [ 1.8496, -0.7179]], device='npu:0')
复制代码
5 小结
经过总体 9 篇的介绍，相信大家已经对 AclConcreteGraph 中的成图有个大概的了解。剩下就剩一个遗留问题，就是GeConcreteGraph，顺便看看GeConcreteGraph与AclConcreteGraph之间的差别。
