商品中心—自研缓存框架的技术文档

@Configurationpublic class ConsumerBeanConfig {    //配置内容对象    @Autowired    private RocketMQProperties rocketMQProperties;        //监听商品修改的MQ消息    @Bean("productUpdateTopic")    public DefaultMQPushConsumer productUpdateTopic(ProductUpdateListener productUpdateListener) throws MQClientException {        DefaultMQPushConsumer consumer = new DefaultMQPushConsumer(RocketMqConstant.PRODUCT_UPDATE_CONSUMER_GROUP);        consumer.setNamesrvAddr(rocketMQProperties.getNameServer());        consumer.subscribe(RocketMqConstant.PRODUCT_UPDATE_TOPIC, "*");        consumer.registerMessageListener(productUpdateListener);        consumer.start();        return consumer;    }}
//商品变更时的缓存处理@Componentpublic class ProductUpdateListener implements MessageListenerConcurrently {    @DubboReference(version = "1.0.0")    private TableDataUpdateApi tableDataUpdateApi;        @Override    public ConsumeConcurrentlyStatus consumeMessage(List<MessageExt> list, ConsumeConcurrentlyContext consumeConcurrentlyContext) {        try {            for (MessageExt messageExt : list) {                //消息处理这里，涉及到sku的缓存更新以及对应的整个商品明细的缓存更新                String msg = new String(messageExt.getBody());                log.info("执行商品缓存数据更新逻辑，消息内容：{}", msg);                  TableDataChangeDTO tableDataChangeMessage = JsonUtil.json2Object(msg, TableDataChangeDTO.class);                //更新sku对应的商品缓存信息                tableDataUpdateApi.tableDataChange(tableDataChangeMessage);                //发送回调消息通知                tableDataUpdateApi.sendCallbackMessage(tableDataChangeMessage);            }        } catch (Exception e) {            log.error("consume error, 商品缓存更新失败", e);            //本次消费失败，下次重新消费            return ConsumeConcurrentlyStatus.RECONSUME_LATER;        }        return ConsumeConcurrentlyStatus.CONSUME_SUCCESS;    }}
//商品信息变更服务@DubboService(version = "1.0.0", interfaceClass = TableDataUpdateApi.class, retries = 0)public class TableDataUpdateApiImpl implements TableDataUpdateApi {    @Resource    private FlushRedisCache flushRedisCache;        private ExecutorService executorService = Executors.newFixedThreadPool(10);       //商品表数据变更逆向更新缓存    @Override    public JsonResult tableDataChange(TableDataChangeDTO tableDataChangeDTO) {        executorService.execute(() -> {            try {                //刷新缓存数据                flushRedisCache.flushRedisStringData(false, tableDataChangeDTO.getTableName(), Sets.newHashSet(tableDataChangeDTO.getKeyId()));            } catch (Exception e) {                log.error("刷新string类型缓存异常，入参为tableDataChangeDTO={}", tableDataChangeDTO, e);            }            try {                flushRedisCache.flushRedisSetData(false, tableDataChangeDTO.getTableName(), Sets.newHashSet(tableDataChangeDTO.getKeyId()));            } catch (Exception e) {                log.error("刷新set类型缓存异常，入参为tableDataChangeDTO={}", tableDataChangeDTO, e);            }            try {                flushRedisCache.flushRedisSortedSetData(false, tableDataChangeDTO.getTableName(), Sets.newHashSet(tableDataChangeDTO.getKeyId()));            } catch (Exception e) {                log.error("刷新sortedset类型缓存异常，入参为tableDataChangeDTO={}", tableDataChangeDTO, e);            }        });        return JsonResult.buildSuccess();    }    ...}
//数据变更—刷新缓存@Componentpublic class FlushRedisCache {    //继承了AbstractRedisStringCache的缓存实例会被注入到abstractRedisStringCacheMap这个map中    //例如CategoryBaseCache、FrontCategoryCache、ItemCollectCache、ProductDetailCache、SkuCollectCache等    @Autowired    private Map<String, AbstractRedisStringCache> abstractRedisStringCacheMap;        //更新string类型缓存    //@param flushAll  是否全量刷新    //@param tableName 表名    //@param idSet     主键ID集合    public void flushRedisStringData(boolean flushAll, String tableName, Set<Long> idSet) {        for (Map.Entry<String, AbstractRedisStringCache> entry : abstractRedisStringCacheMap.entrySet()) {            AbstractRedisStringCache stringCache = entry.getValue();            if (flushAll) {                stringCache.flushRedisStringDataByTableUpdateData();                continue;            }            //继承AbstractRedisStringCache的每个缓存实例都指定来表名，如下用于匹配出对应的缓存实例            if (stringCache.getTableName().contains(tableName)) {                stringCache.flushRedisStringDataByTableAndIdSet(tableName, idSet);            }        }    }    ...}
//Redis(string)缓存抽象类public abstract class AbstractRedisStringCache<DO, BO> {    @Resource    private RedisReadWriteManager redisReadWriteManager;    ...        //刷新缓存—根据主表ID集合（关联表变更需要查询主表）    public void flushRedisStringDataByTableAndIdSet(String tableName, Set<Long> idSet) {        Optional<Set<Long>> idSetOpt = getStringDatabase().getTableIdSetByRelationTableIdSet(tableName, idSet);        if (!idSetOpt.isPresent()) {            return;        }        flushRedisStringDataByIdSet(idSetOpt.get());    }        //刷新缓存—根据主键ID集合    //@param idSet 数据表主键ID    private void flushRedisStringDataByIdSet(Set<Long> idSet) {        //根据id集合从数据库中查询出数据        Optional<RedisStringCache<DO>> stringSourceOpt = getStringDatabase().listTableDataByIdSet(idSet, queryType());        if (!stringSourceOpt.isPresent()) {            return;        }        RedisStringCache<DO> redisStringCache = stringSourceOpt.get();        if (!CollectionUtils.isEmpty(redisStringCache.getDeleteSet())) {            //通过缓存读写组件删除缓存            redisReadWriteManager.delete(redisStringCache.getDeleteSet().stream().map(this::getRedisKey).collect(toSet()).toArray(new String[]{}));        }        if (CollectionUtils.isEmpty(redisStringCache.getAddList())) {            return;        }        List<BO> boList = convertDO2BO(redisStringCache.getAddList());        Map<String, BO> redisMap = convertBO2Map(boList);        //通过缓存读写组件写入缓存        redisReadWriteManager.batchWriteRedisString(redisMap);    }    ...}
//缓存读写管理@Servicepublic class RedisReadWriteManager {    @Resource    private RedisCache redisCache;    ...        //删除指定的key    public void delete(String... keys) {        Arrays.asList(keys).stream().forEach(key -> redisCache.delete(key));    }        //批量添加string缓存    public <T> void batchWriteRedisString(Map<String, T> redisMap) {        List<Map.Entry<String, T>> list = Lists.newArrayList(redisMap.entrySet());        try {            for (List<Map.Entry<String, T>> entries : Lists.partition(list, PAGE_SIZE_100)) {                for (Map.Entry<String, T> entry : entries) {                    redisCache.setex(true, entry.getKey(), JSON.toJSONString(entry.getValue()), RedisKeyUtils.redisKeyRandomTime(INT_EXPIRED_SEVEN_DAYS));                }                try {                    Thread.sleep(SLEEP_100);                } catch (InterruptedException e) {                    e.printStackTrace();                }            }        } catch (Exception e) {            log.error("批量添加string缓存异常 redisMap={}", redisMap, e);        }    }    ...}

@Componentpublic class FlushRedisCache {    //继承了AbstractRedisStringCache的缓存实例会被注入到abstractRedisStringCacheMap这个map中    //例如CategoryBaseCache、FrontCategoryCache、ItemCollectCache、ProductDetailCache、SkuCollectCache等    @Autowired    private Map<String, AbstractRedisStringCache> abstractRedisStringCacheMap;
    //继承了AbstractRedisSortedSetCache的缓存实例会被注入到abstractRedisSortedSetCacheMap这个map中    //例如SkuSellerCache    @Autowired    private Map<String, AbstractRedisSortedSetCache> abstractRedisSortedSetCacheMap;    ...}
@Service("productDetailCache")public class ProductDetailCache extends AbstractRedisStringCache<ProductDetailDO, ProductDetailBO> {    //DB操作组件    @Resource    private ProductDetailStringDatabase productDetailStringDatabase;        @Resource    private ProductDetailConverter productDetailConverter;        @Override    protected RedisStringDatabase<ProductDetailDO> getStringDatabase() {        return productDetailStringDatabase;    }        @Override    protected String getPendingRedisKey() {        return AbstractRedisKeyConstants.PRODUCT_SKU_INFO_STRING;    }        @Override    protected List<ProductDetailBO> convertDO2BO(Collection<ProductDetailDO> doList) {        return productDetailConverter.converterDetailList(doList);    }        @Override    protected Map<String, Object> getTableFieldsMap(String key) {        Map<String, Object> dbInputMap = Maps.newHashMap();        dbInputMap.put(SkuCollectStringDatabase.SKU_ID, key);        return dbInputMap;    }        @Override    protected Class<ProductDetailBO> getBOClass() {        return ProductDetailBO.class;    }    ...}
//Redis(string)缓存抽象类//@param <DO> 数据对象//@param <BO> 缓存对象public abstract class AbstractRedisStringCache<DO, BO> {    @Resource    private RedisReadWriteManager redisReadWriteManager;        //获取redis key    //@param key 需要替换的关键字    protected String getRedisKey(String key) {        return String.format(getPendingRedisKey(), key);    }        //单个获取数据库表名    public String getTableName() {        return getStringDatabase().getTableName();    }        //获取DB读取对象    protected abstract RedisStringDatabase<DO> getStringDatabase();        //获取待处理的Redis key    protected abstract String getPendingRedisKey();        //DO转BO    protected abstract List<BO> convertDO2BO(Collection<DO> doList);        //关联表字段值    protected abstract Map<String, Object> getTableFieldsMap(String key);        //获取BO对象的class    protected abstract Class<BO> getBOClass();    ...        //模版方法：根据关键字批量获取数据    //@param useLocalCache 是否使用本地缓存    //@param keyList       入参关键字    public Optional<List<BO>> listRedisStringData(Boolean useLocalCache, List<String> keyList) {        if (CollectionUtils.isEmpty(keyList)) {            return Optional.empty();        }        Optional<List<BO>> boListOpt = redisReadWriteManager.listRedisStringDataByCache(useLocalCache, keyList,            getBloomKey(), getStringDatabase()::getTableSingleFiled, getStringDatabase().getBloomField(),            getBOClass(), this::getRedisKey, (key) -> {                Map<String, Object> tableFieldsMap = getTableFieldsMap(key);                Optional<DO> doOpt;                try {                    doOpt = getStringDatabase().getTableData(tableFieldsMap, queryType());                } catch (Exception e) {                    log.error("根据关键字批量获取数据异常 key={},paramMap={}", key, tableFieldsMap, e);                    return Optional.empty();                }                if (!doOpt.isPresent()) {                    return Optional.empty();                }                List<BO> boList = convertDO2BO(Arrays.asList(doOpt.get()));                if (CollectionUtils.isEmpty(boList)) {                    return Optional.empty();                }                return Optional.of(boList.get(0));            }        );        return boListOpt;    }        //模版方法：根据多关键字批量获取集合数据    //@param keyList    入参关键字    //@param requestMap key 数据库表字段，value 字段值，该map中的字段不要与getTableFieldsMap(key)获取的字段重复    public Optional<List<BO>> listRedisStringData(List<String> keyList, Map<String, Object> requestMap) {        if (CollectionUtils.isEmpty(keyList)) {            return Optional.empty();        }        Optional<List<BO>> boListOpt = redisReadWriteManager.listRedisStringDataByBatchCache(keyList, getBOClass(), this::getRedisKey, (key) -> {            Map<String, Object> tableFieldsMap = getTableFieldsMap(key);            if (MapUtils.isNotEmpty(requestMap)) {                tableFieldsMap.putAll(requestMap);            }            Optional<List<DO>> doOpt;            try {                doOpt = getStringDatabase().listTableData(tableFieldsMap, queryType());            } catch (Exception e) {                log.error("根据关键字批量获取数据异常 key={},paramMap={}", key, tableFieldsMap, e);                return Optional.empty();            }            if (!doOpt.isPresent()) {                return Optional.empty();            }            List<BO> boList = convertDO2BO(doOpt.get());            if (CollectionUtils.isEmpty(boList)) {                return Optional.empty();            }            return Optional.of(boList);        });        return boListOpt;    }        //模版方法：刷新缓存—根据主表ID集合（关联表变更需要查询主表）    //@param tableName 关联表名    //@param idSet     关联表主键集合    public void flushRedisStringDataByTableAndIdSet(String tableName, Set<Long> idSet) {        Optional<Set<Long>> idSetOpt = getStringDatabase().getTableIdSetByRelationTableIdSet(tableName, idSet);        if (!idSetOpt.isPresent()) {            return;        }        flushRedisStringDataByIdSet(idSetOpt.get());    }        //模版方法：刷新缓存—根据表变更数据ID集合    public void flushRedisStringDataByTableUpdateData() {        Optional<Set<Long>> updateIdSetOpt = getStringDatabase().getTableUpdateIdSet();        if (!updateIdSetOpt.isPresent()) {            return;        }        flushRedisStringDataByIdSet(updateIdSetOpt.get());    }        //模版方法：刷新缓存—根据主键ID集合    //@param idSet 数据表主键ID    private void flushRedisStringDataByIdSet(Set<Long> idSet) {        //根据id集合从数据库中查询出数据        Optional<RedisStringCache<DO>> stringSourceOpt = getStringDatabase().listTableDataByIdSet(idSet, queryType());        if (!stringSourceOpt.isPresent()) {            return;        }        RedisStringCache<DO> redisStringCache = stringSourceOpt.get();        if (!CollectionUtils.isEmpty(redisStringCache.getDeleteSet())) {            //通过缓存读写组件删除缓存            redisReadWriteManager.delete(redisStringCache.getDeleteSet().stream().map(this::getRedisKey).collect(toSet()).toArray(new String[]{}));        }        if (CollectionUtils.isEmpty(redisStringCache.getAddList())) {            return;        }        List<BO> boList = convertDO2BO(redisStringCache.getAddList());        Map<String, BO> redisMap = convertBO2Map(boList);        //通过缓存读写组件写入缓存        redisReadWriteManager.batchWriteRedisString(redisMap);    }    ...}

//缓存读写管理@Servicepublic class RedisReadWriteManager {    @Resource    private RedisCache redisCache;        @Resource    private RedisLock redisLock;    ...        //删除指定的key    public void delete(String... keys) {        Arrays.asList(keys).stream().forEach(key -> redisCache.delete(key));    }        //批量添加string缓存    public <T> void batchWriteRedisString(Map<String, T> redisMap) {        List<Map.Entry<String, T>> list = Lists.newArrayList(redisMap.entrySet());        try {            for (List<Map.Entry<String, T>> entries : Lists.partition(list, PAGE_SIZE_100)) {                for (Map.Entry<String, T> entry : entries) {                    redisCache.setex(true, entry.getKey(), JSON.toJSONString(entry.getValue()), RedisKeyUtils.redisKeyRandomTime(INT_EXPIRED_SEVEN_DAYS));                }                try {                    Thread.sleep(SLEEP_100);                } catch (InterruptedException e) {                    e.printStackTrace();                }            }        } catch (Exception e) {            log.error("批量添加string缓存异常 redisMap={}", redisMap, e);        }    }        //批量获取多缓存数据    public <T> Optional<List<T>> listRedisStringDataByBatchCache(List<String> keyList, Class<T> clazz, Function<String, String> getRedisKeyFunction, Function<String, Optional<List<T>>> getDbFuction) {        try {            List<T> list = Lists.newArrayList();            List<String> pendingKeyList = keyList.stream().distinct().collect(toList());            List<String> redisKeyList = pendingKeyList.stream().map(getRedisKeyFunction).distinct().collect(toList());            List<String> cacheList = redisCache.mget(redisKeyList);            for (int i = 0; i < cacheList.size(); i++) {                String cache = cacheList.get(i);                //过滤无效缓存                if (EMPTY_OBJECT_STRING.equals(cache)) {                    continue;                }                if (StringUtils.isNotBlank(cache)) {                    List<T> tList = JSON.parseArray(cache, clazz);                    list.addAll(tList);                    continue;                }                //缓存没有则读库                Optional<List<T>> optional = listRedisStringDataByDb(pendingKeyList.get(i), getRedisKeyFunction, getDbFuction);                if (optional.isPresent()) {                    list.addAll(optional.get());                }            }            return CollectionUtils.isEmpty(list) ? Optional.empty() : Optional.of(list);        } catch (Exception e) {            log.error("批量获取缓存数据异常 keyList={},clazz={}", keyList, clazz, e);            throw e;        }    }        //读取数据库表多数据赋值到Redis    public <T> Optional<List<T>> listRedisStringDataByDb(String key, Function<String, String> getRedisKeyFunction, Function<String, Optional<List<T>>> getDbFuction) {        if (StringUtils.isEmpty(key) || Objects.isNull(getDbFuction)) {            return Optional.empty();        }        try {            if (!redisLock.lock(key)) {                return Optional.empty();            }            String redisKey = getRedisKeyFunction.apply(key);            Optional<List<T>> optional = getDbFuction.apply(key);            if (!optional.isPresent()) {                //把空对象暂存到redis                redisCache.setex(true, redisKey, EMPTY_OBJECT_STRING, RedisKeyUtils.redisKeyRandomTime(INT_EXPIRED_ONE_DAY, TimeUnit.HOURS, NUMBER_24));                log.warn("发生缓存穿透 redisKey={}", redisKey);                return optional;            }            //把表数据对象存到redis            redisCache.setex(true, redisKey, JSON.toJSONString(optional.get()), RedisKeyUtils.redisKeyRandomTime(INT_EXPIRED_SEVEN_DAYS));            log.info("表数据对象存到Redis redisKey={}, data={}", redisKey, optional.get());            return optional;        } finally {            redisLock.unlock(key);        }    }    ...}

@Service("productDetailStringDatabase")public class ProductDetailStringDatabase extends AbstractRedisStringDatabase<ProductDetailDO> {    public static final String SKU_ID = "skuId";    private static final String TABLE_NAME = "sku_info";        @Resource    private ProductRepository productRepository;        @Override    public String getTableName() {        return TABLE_NAME;    }        @Override    public Set<String> getTableNameSet() {        return Sets.newHashSet(getTableName());    }        @Override    public Optional<ProductDetailDO> getTableData(Map<String, Object> tableFieldsMap, String queryType) {        if (tableFieldsMap.containsKey(SKU_ID)) {            String skuId = (String) tableFieldsMap.get(SKU_ID);            ProductDetailDO productDetailDO = productRepository.queryProductDetail(skuId);            if (!Objects.isNull(productDetailDO) && DelFlagEnum.EFFECTIVE.getCode().equals(productDetailDO.getDelFlag())) {                return Optional.of(productDetailDO);            }            return Optional.empty();        }        return Optional.empty();    }        @Override    public Optional<List<ProductDetailDO>> listTableData(Map<String, Object> tableFieldsMap, String queryType) {        return Optional.empty();    }        @Override    public Optional<RedisStringCache<ProductDetailDO>> listTableDataByIdSet(Set<Long> idSet, String queryType) {        RedisStringCache redisStringCache = new RedisStringCache();        List<ProductDetailDO> addList = new ArrayList<>();        for (Long skuId : idSet) {            ProductDetailDO productDetailDO = productRepository.queryProductDetail(String.valueOf(skuId));            if (!Objects.isNull(productDetailDO)) {                addList.add(productDetailDO);            }        }        redisStringCache.setAddList(addList);        return Optional.of(redisStringCache);    }        @Override    public Optional<RedisStringCache<ProductDetailDO>> listTableDataByIdSet(List<Long> idSet, String queryType) {        Long skuId = idSet.get(0);        ProductDetailDO productDetailDO = productRepository.queryProductDetail(String.valueOf(skuId));        RedisStringCache redisStringCache = new RedisStringCache();        redisStringCache.setAddList(Arrays.asList(productDetailDO));        return Optional.of(redisStringCache);    }}
