一、背景
亲测可用,之前搜索了很多博客，啥样的都有，就是不介绍报错以及配置用处，根本不懂照抄那些配置是干啥的，稀里糊涂的按照博客搭完也跑不起来，因此记录这个。
项目背景：公司项目当前采用 http 协议+shiro+mysql 的登录认证方式，而现在想支持 ldap 协议认证登录然后能够访问自己公司的项目网站。
举例说明：假设我们公司有自己的门户网站，现在我们收购了一家公司，他们数据库采用 ldap 存储用户数据，那么为了他们账户能登陆我们公司项目所以需要集成，而不是再把他们的账户重新在 mysql 再创建一遍，万一人家有 1W 个账户呢，不累死了且也不现实啊。
需要安装 openldap+kerberos，且 ldap 和 kerberos 安装在同一台服务器上，当前版本如下：
另外介绍下我的 Spring 各个版本：
Spring Security：4.2.3.RELEASE
Spring Version：4.3.9.RELEASE
SpringBoot Version：1.4.7.RELEASE
注意点1：我之所以选这么旧的版本，是因为我最后要在自己项目集成，我们项目就是上面版本附近的，所以不能选太高版本，这点请注意各版本之间的兼容性问题。详情可看这篇博客介绍兼容版本：https://zhuanlan.zhihu.com/p/652895555
注意点2：如果里面的某些配置不知道在哪或者不知道干啥的，可以看我的前面的博客，详细介绍了安装配置等，可以大致了解参数。
目前网上相关文章很少，而且好多博客都是未认证就发布的所以一堆问题，跑不起来，如下是我参考的博客
二、报错
完整错误
[Krb5LoginModule] authentication failed null (68) [LoginContext]: login REQUIRED failure [LoginContext]: abort ignoredjavax.security.auth.login.LoginException: null (68) at com.sun.security.auth.module.Krb5LoginModule.attemptAuthentication(Krb5LoginModule.java:804) at com.sun.security.auth.module.Krb5LoginModule.login(Krb5LoginModule.java:617) at sun.reflect.NativeMethodAccessorImpl.invoke0(Native Method) at sun.reflect.NativeMethodAccessorImpl.invoke(NativeMethodAccessorImpl.java:62) at sun.reflect.DelegatingMethodAccessorImpl.invoke(DelegatingMethodAccessorImpl.java:43) at java.lang.reflect.Method.invoke(Method.java:498) at javax.security.auth.login.LoginContext.invoke(LoginContext.java:755) at javax.security.auth.login.LoginContext.access$000(LoginContext.java:195) at javax.security.auth.login.LoginContext$4.run(LoginContext.java:682) at javax.security.auth.login.LoginContext$4.run(LoginContext.java:680) at java.security.AccessController.doPrivileged(Native Method) at javax.security.auth.login.LoginContext.invokePriv(LoginContext.java:680) at javax.security.auth.login.LoginContext.login(LoginContext.java:587) at com.example.ldaptest2.KerberosTest.authenticateUser2(KerberosTest.java:58) at sun.reflect.NativeMethodAccessorImpl.invoke0(Native Method) at sun.reflect.NativeMethodAccessorImpl.invoke(NativeMethodAccessorImpl.java:62) at sun.reflect.DelegatingMethodAccessorImpl.invoke(DelegatingMethodAccessorImpl.java:43) at java.lang.reflect.Method.invoke(Method.java:498) at org.junit.runners.model.FrameworkMethod$1.runReflectiveCall(FrameworkMethod.java:59) at org.junit.internal.runners.model.ReflectiveCallable.run(ReflectiveCallable.java:12) at org.junit.runners.model.FrameworkMethod.invokeExplosively(FrameworkMethod.java:56) at org.junit.internal.runners.statements.InvokeMethod.evaluate(InvokeMethod.java:17) at org.springframework.test.context.junit4.statements.RunBeforeTestMethodCallbacks.evaluate(RunBeforeTestMethodCallbacks.java:75) at org.springframework.test.context.junit4.statements.RunAfterTestMethodCallbacks.evaluate(RunAfterTestMethodCallbacks.java:86) at org.springframework.test.context.junit4.statements.SpringRepeat.evaluate(SpringRepeat.java:84) at org.junit.runners.ParentRunner.runLeaf(ParentRunner.java:366) at org.springframework.test.context.junit4.SpringJUnit4ClassRunner.runChild(SpringJUnit4ClassRunner.java:252) at org.springframework.test.context.junit4.SpringJUnit4ClassRunner.runChild(SpringJUnit4ClassRunner.java:94) at org.junit.runners.ParentRunner$4.run(ParentRunner.java:331) at org.junit.runners.ParentRunner$1.schedule(ParentRunner.java:79) at org.junit.runners.ParentRunner.runChildren(ParentRunner.java:329) at org.junit.runners.ParentRunner.access$100(ParentRunner.java:66) at org.junit.runners.ParentRunner$2.evaluate(ParentRunner.java:293) at org.springframework.test.context.junit4.statements.RunBeforeTestClassCallbacks.evaluate(RunBeforeTestClassCallbacks.java:61) at org.springframework.test.context.junit4.statements.RunAfterTestClassCallbacks.evaluate(RunAfterTestClassCallbacks.java:70) at org.junit.runners.ParentRunner$3.evaluate(ParentRunner.java:306) at org.junit.runners.ParentRunner.run(ParentRunner.java:413) at org.springframework.test.context.junit4.SpringJUnit4ClassRunner.run(SpringJUnit4ClassRunner.java:191) at org.junit.runner.JUnitCore.run(JUnitCore.java:137) at com.intellij.junit4.JUnit4IdeaTestRunner.startRunnerWithArgs(JUnit4IdeaTestRunner.java:69) at com.intellij.rt.junit.IdeaTestRunner$Repeater.startRunnerWithArgs(IdeaTestRunner.java:33) at com.intellij.rt.junit.JUnitStarter.prepareStreamsAndStart(JUnitStarter.java:220) at com.intellij.rt.junit.JUnitStarter.main(JUnitStarter.java:53)Caused by: KrbException: null (68) at sun.security.krb5.KrbAsRep.<init>(KrbAsRep.java:76) at sun.security.krb5.KrbAsReqBuilder.send(KrbAsReqBuilder.java:316) at sun.security.krb5.KrbAsReqBuilder.action(KrbAsReqBuilder.java:361) at com.sun.security.auth.module.Krb5LoginModule.attemptAuthentication(Krb5LoginModule.java:776) ... 42 moreCaused by: KrbException: Identifier doesn't match expected value (906) at sun.security.krb5.internal.KDCRep.init(KDCRep.java:140) at sun.security.krb5.internal.ASRep.init(ASRep.java:64) at sun.security.krb5.internal.ASRep.<init>(ASRep.java:59) at sun.security.krb5.KrbAsRep.<init>(KrbAsRep.java:60) ... 45 more2024-06-14 16:44:15.708 INFO 18160 --- [ Thread-1] o.s.w.c.s.GenericWebApplicationContext : Closing org.springframework.web.context.support.GenericWebApplicationContext@18025ced: startup date [Fri Jun 14 16:44:04 CST 2024]; root of context hierarchyDisconnected from the target VM, address: '127.0.0.1:12344', transport: 'socket'LSA: Found TicketLSA: Made NewWeakGlobalRefLSA: Found PrincipalNameLSA: Made NewWeakGlobalRefLSA: Found DerValueLSA: Made NewWeakGlobalRefLSA: Found EncryptionKeyLSA: Made NewWeakGlobalRefLSA: Found TicketFlagsLSA: Made NewWeakGlobalRefLSA: Found KerberosTimeLSA: Made NewWeakGlobalRefLSA: Found StringLSA: Made NewWeakGlobalRefLSA: Found DerValue constructorLSA: Found Ticket constructorLSA: Found PrincipalName constructorLSA: Found EncryptionKey constructorLSA: Found TicketFlags constructorLSA: Found KerberosTime constructorLSA: Finished OnLoad processing
Process finished with exit code 0
复制代码
错误原因1：keytab 过期了
举例验证
[root@localhost ~]# ls -l /etc/openldap/ldap.keytab-rwxrwxrwx 1 ldap ldap 1058 6月 14 02:22 /etc/openldap/ldap.keytab[root@localhost ~]# 等待输入超时：自动登出
复制代码
解决方案：重新生成 keytab 就行
错误原因2：本地和服务器时间不一致解决方案：同步时间
