架构师训练营第三章作业

发布于: 2020 年 06 月 24 日
  1. 手写单例类

利用静态内部类式实现,懒加载,线程安全

  1. 使用组合模式打印窗口组件

public interface Component {
void draw();
}
public class Node implements Component{
private List<Component> children;
private String name;
public String getName() {
return name;
}
public void setName(String name) {
this.name = name;
}
public Node(String name) {
this.name = name;
this.children = new ArrayList<>();
}
public void addChild(Component component){
this.children.add(component);
}
@Override
public void draw() {
System.out.println("print "+ this.name);
this.children.forEach(Component::draw);
}
}
public class Leaf implements Component{
private String name;
public Leaf(String name){
this.name = name;
}
public String getName() {
return name;
}
public void setName(String name) {
this.name = name;
}
@Override
public void draw() {
System.out.println("print " + this.name);
}
}
public class Test {
public static void main(String[] args) {
Node winForm = new Node("WinForm(WINDOW窗口)");
winForm.addChild(new Leaf("Picture(Logo图片)"));
winForm.addChild(new Leaf("Button(登录)"));
winForm.addChild(new Leaf("Button(注册)"));
Node frame = new Node("Frame(FRAME1)");
frame.addChild(new Leaf("Label(用户名)"));
frame.addChild(new Leaf("TextBox(文本框)"));
frame.addChild(new Leaf("Label(密码)"));
frame.addChild(new Leaf("PasswordBox(密码框)"));
frame.addChild(new Leaf("Checkbox(复选框)"));
frame.addChild(new Leaf("TextBox(记住用户名)"));
frame.addChild(new Leaf("LinkLabel(忘记密码)"));
winForm.addChild(frame);
winForm.draw();
}
}

..................................................................................................................................................................................
