问题背景
DolphinScheduler 1.3.9 版本
查询任务实例列表等接口时，有时会出现响应慢的情况，超过 20 秒才返回结果。
问题诊断
（1）mysql 开启慢日志
/etc/mysql.cnf 添加如下配置参数
slow_query_log = ON slow_query_log_file = /data/log/mysql/mysql-slow.log long_query_time = 2
复制代码
（2）慢日志分析
日志中以下几类 sql 超时频率较高：
select * from t_ds_process_instance where 1=1 and state in ( 0 , 1 , 2 , 4 ) and process_definition_id=71 and (schedule_time >= '2022-07-20 00:00:00' and schedule_time <= '2022-07-20 23:59:59.999' or start_time >= '2022-07-20 00:00:00' and start_time <= '2022-07-20 23:59:59.999') order by start_time desc limit 1;
复制代码
select instance.*,process.name as process_instance_name from t_ds_task_instance instance left join t_ds_process_definition define on instance.process_definition_id = define.id left join t_ds_process_instance process on process.id=instance.process_instance_id where define.project_id = 6 order by instance.start_time desc LIMIT 0,10;
复制代码
主要涉及t_ds_process_instance和t_ds_task_instance两张表。
通过explain analyze命令分析，可以发现第一类 sql 使用start_time_index这个索引查询的过程中耗时较多，start_time_index区分度较差，需要有更好区分度的索引来提升查询速度；
-> Limit: 1 row(s) (cost=0.20 rows=0) (actual time=103.391..103.391 rows=1 loops=1) -> Filter: ((t_ds_process_instance.process_definition_id = 18) and (((t_ds_process_instance.schedule_time >= TIMESTAMP'2022-07-18 00:00:00') and (t_ds_process_instance.schedule_time <= TIMESTAMP'2022-07-18 23:59:59.999')) or ((t_ds_process_instance.start_time >= TIMESTAMP'2022-07-18 00:00:00') and (t_ds_process_instance.start_time <= TIMESTAMP'2022-07-18 23:59:59.999')))) (cost=0.20 rows=0) (actual time=103.391..103.391 rows=1 loops=1) -> Index scan on t_ds_process_instance using start_time_index (reverse) (cost=0.20 rows=2) (actual time=0.030..103.165 rows=1239 loops=1)
复制代码
第二类 sql 主要耗时在 left join 阶段，需要更新索引字段
-> Limit: 10 row(s) (actual time=3601.141..3601.147 rows=10 loops=1) -> Sort row IDs: `instance`.start_time DESC, limit input to 10 row(s) per chunk (actual time=3601.140..3601.145 rows=10 loops=1) -> Table scan on <temporary> (cost=0.01..3774.21 rows=301738) (actual time=0.002..190.179 rows=722743 loops=1) -> Temporary table (cost=469419.96..473194.16 rows=301738) (actual time=3332.896..3551.716 rows=722743 loops=1) -> Nested loop left join (cost=439246.15 rows=301738) (actual time=0.051..1431.254 rows=722743 loops=1) -> Nested loop inner join (cost=107334.40 rows=301738) (actual time=0.045..1239.699 rows=722743 loops=1) -> Filter: (define.id is not null) (cost=12.40 rows=121) (actual time=0.025..0.162 rows=121 loops=1) -> Index lookup on define using process_definition_index (project_id=6) (cost=12.40 rows=121) (actual time=0.025..0.110 rows=121 loops=1) -> Index lookup on instance using task_instance_index (process_definition_id=define.id) (cost=639.65 rows=2494) (actual time=0.006..9.972 rows=5973 loops=121) -> Single-row index lookup on process using PRIMARY (id=`instance`.process_instance_id) (cost=1.00 rows=1) (actual time=0.000..0.000 rows=1 loops=722743)
复制代码
（3）问题定位
innodb_buffer_pool_size（InnoDB 使用一个缓冲池来保存索引和原始数据）。
innodb_thread_concurrency（设置为 0,表示不限制并发数，这里推荐设置为 0，更好去发挥 CPU 多核处理能力，提高并发量）
innodb_write_io_threads & innodb_read_io_threads （innodb 使用后台线程处理数据页上的读写 I/O 请求）需要调整以上参数，提高 mysql 性能。
优化内容
（1）大表归档
根据t_ds_process_instance DDL建表语句复制表t_ds_process_instance_bak。
根据t_ds_task_instance DDL建表语句复制表 t_ds_task_instance_bak。
注：外键行删除
CONSTRAINT foreign_key_instance_id FOREIGN KEY (process_instance_id) REFERENCES t_ds_process_instance (id) ON DELETE CASCADE ON UPDATE RESTRICT
INSERT into t_ds_process_instance_copy select * from t_ds_process_instance WHERE start_time < '2022-01-01 00:00:00';
复制代码
INSERT into t_ds_task_instance_copy select * from t_ds_task_instance WHERE start_time < '2022-01-01 00:00:00';
复制代码
select count(*) from t_ds_process_instance_copy; select count(*) from t_ds_process_instance where start_time < '2022-01-01 00:00:00'; select count(*) from t_ds_task_instance_copy; select count(*) from t_ds_task_instance where start_time < '2022-01-01 00:00:00';
复制代码
DELETE FROM t_ds_process_instance WHERE start_time < '2022-01-01 00:00:00'; DELETE FROM t_ds_task_instance WHERE start_time < '2022-01-01 00:00:00';
复制代码
（2）参数优化
/etc/my.cnf mysql配置文件中调整如下参数并重启 mysql
innodb_log_buffer_size= 64M innodb_buffer_pool_size= 20G //（根据服务器内存适当调整）如果数据库独占一台机器则设置物理内存的70% innodb_log_file_size= 1G innodb_thread_concurrency = 0 join_buffer_size = 64M sort_buffer_size = 64M innodb_read_io_threads = 16 //（根据服务器CPU适当调整） innodb_write_io_threads = 16 //（根据服务器CPU适当调整）
复制代码
（3）索引优化
create index state_index on t_ds_process_instance(state, process_definition_id); create index start_time_process_definition_index on t_ds_task_instance(start_time, process_definition_id); alter table t_ds_task_instance drop index task_instance_index;
复制代码
转载自 daozi126
原文链接：https://blog.csdn.net/u012938208/article/details/147899920
